| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HA6219 | HOSE (PARKING BRAKE) | 1 | ||||
| ? | HA6702 | HOSE (SERVICE BRAKES) | 1 | ||||
| ? | WB0581 | FITTING, STRAIGHT | 1 | ||||
| ? | HA6645 | HOSE (TO RH & LH PARKING BRAKE) | 2 | ||||
| ? | WB0381 | FITTING, TEE | 1 | ||||
| ? | WA4871 | CLAMP, HYDRA-ZORB - 1/2" | 3 | ||||
| ? | WB0576 | FITTING, STRAIGHT | 1 | ||||
| ? | VM0315 | PLUG | 2 | ||||
| ? | WB0584 | FITTING, STRAIGHT | 2 | ||||
| ? | WB0384 | FITTING, TEE | 1 | ||||
| ? | HA7369 | HOSE (TO RH & LH SERVICE BRAKE) | 2 | ||||
| ? | WA4875 | CLAMP, HYDRA-ZORB - 3/8" | 3 | ||||
| ? | WB3093 | CLAMP, CUSHION - 1" | 5 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 10 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 10 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 10 | ||||
| ? | WA4703 | CLAMP, HYDRA-ZORB - 3/8" | 6 | ||||
| ? | WA4704 | CLAMP, HYDRA-ZORB - 1/2" | 6 | ||||
| ? | TY9275 | TUBE | 1 | ||||
| ? | TZ0226 | TUBE | 1 | ||||
| ? | TZ0228 | TUBE | 1 | ||||
| ? | TZ0229 | TUBE | 1 | ||||
| ? | WB3092 | CLAMP, CUSHION - 7/8" | 5 | ||||
| ? | WB1304 | CLAMP, CUSHION - 9/16" | 5 | ||||
| ? | WB1303 | CLAMP, CUSHION - 3/4" | 5 | ||||
| ? | HA5568 | HOSE (SERVICE BRAKES) | 1 | ||||
| ? | HA5816 | HOSE (PARKING BRAKE) | 1 |
