| Наименование | Страница | Код страницы |
|---|---|---|
| LIGHT ASSEMBLY (SUPER HALOGEN) 2/2 | 388 | 42185 |
| JUNCTION BOX ASSEMBLY - REAR EM6434 | 384 | 60960 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EM6434 | JUNCTION BOX ASSEMBLY - REAR (SEE INDEX) | 1 | 60960 | |||
| ? | MM0025 | CAPSCREW - M6 X 1.00 X 20 | 4 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 4 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 4 | ||||
| ? | XB3429 | HARNESS, RIGHT REAR FRAME | 1 | ||||
| ? | TR9441 | CLAMP, VINYL - 1 1/4" | 3 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 15 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 15 | ||||
| ? | WB3097 | CLAMP, CUSHION - 1/2" | 5 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 6 | ||||
| ? | WB3092 | CLAMP, CUSHION - 7/8" | 4 | ||||
| ? | EK5647 | HARNESS, BLOWER PRESSURE SWITCH | 1 | ||||
| ? | XB3442 | HARNESS, AXLE HOUSING | 1 | ||||
| ? | 736131C2 | ALARM, BACKUP | 2 | ||||
| ? | C5753 | CAPSCREW - 3/8" - 16NC X 4" | 4 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 4 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 4 | ||||
| ? | SP8708 | LOCKWASHER - 5/16" (EXTERNAL - INTERNAL TOOTH) | 6 | ||||
| ? | PC1913 | STOP/TAIL LIGHT - RED (LED) | 2 | ||||
| ? | AK4695 | • LENS/REFLECTOR UNIT - RED | 1 | ||||
| ? | AK4705 | • HOUSING ASSEMBLY - UNIVERSAL | 1 | ||||
| ? | PC1914 | RETARD LIGHT - AMBER (LED) | 2 | ||||
| ? | AK4696 | • LENS/REFLECTOR UNIT - RETARD | 1 | ||||
| ? | AK4704 | • HOUSING ASSEMBLY - UNIVERSAL | 1 | ||||
| ? | AK7513 | BACKUP LIGHT ASSEMBLY (SEE FIG 42185) | 2 | 42185 | |||
| ? | WB3093 | CLAMP, CUSHION - 1" | 3 |
