| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | BF4994 | STARTER ASSEMBLY (NO PRELUBE) | 2 | ||||
| ? | 09842A0481 | PLATE, SAFETY - JUMP START ENGINE | 2 | ||||
| ? | VL6217 | SWITCH, MAGNETIC | 2 | ||||
| ? | VZ3250 | DIODE | 2 | ||||
| ? | EB5678 | HOUSING | 2 | ||||
| ? | CH4118 | CABLE | 1 | ||||
| ? | CH4123 | CABLE | 1 | ||||
| ? | CH4702 | CABLE | 1 | ||||
| ? | CH4116 | CABLE | 1 | ||||
| ? | CH4605 | CABLE | 1 | ||||
| ? | CH4310 | CABLE | 1 | ||||
| ? | CH4440 | CABLE | 1 | ||||
| ? | EJ9542 | LINK, FUSABLE | 1 | ||||
| ? | EJ9246 | HARNESS, PRE-LUBE | 1 | ||||
| ? | EL4305 | HARNESS, ENGINE (EXTERNAL) | 1 | ||||
| ? | TD1548 | CAPSCREW - 1/4" - 20NC X 5/8" | 8 | ||||
| ? | C1546 | FLAT WASHER - 1/4" | 12 | ||||
| ? | C7588 | CAPSCREW - 1/4" - 20NC X 1" | 6 | ||||
| ? | C5774 | LOCKWASHER - 1/4" | 6 | ||||
| ? | C5780 | NUT - 1/4" - 20NC | 6 | ||||
| ? | PC1000 | MOUNT, RUBBER | 3 | ||||
| ? | WA0720 | FLAT WASHER - 3/8" (HARDENED) | 6 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 3 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 3 | ||||
| ? | TC1234 | CAPSCREW - 3/8" - 16NC X 3/4" | 2 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 2 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 2 | ||||
| ? | CH4115 | CABLE | 1 | ||||
| ? | C5768 | PLUG, PIPE - 1/8" | 1 | ||||
| ? | EJ2967 | BRACKET | 1 | ||||
| ? | 677161R94 | SENDER, PRESSURE (ENGINE OIL PRESSURE) | 1 | ||||
| ? | VF7730 | SWITCH, PRESSURE (ENGINE HOURS) | 1 | ||||
| ? | VZ0589 | SWITCH, PRESSURE (STARTER LOCKOUT) | 1 | ||||
| ? | WB0456 | FITTING, 37 DEG FLARE, STRAIGHT ADAPTER | 1 | ||||
| ? | HA2365 | HOSE | 1 | ||||
| ? | (NOT USED IN THIS APPLICATION) | 1 | |||||
| ? | PC0122 | SEAL, ADAPTER | 1 | ||||
| ? | PC0119 | CABLE | 1 | ||||
| ? | 803800519 | CAP, TERMINAL | 4 | ||||
| ? | 803802027 | CAP, TERMINAL | 5 | ||||
| ? | 80380430 | CAP, TERMINAL | 3 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | EJ2963 | COVER, PRELUBE SWITCH/TIMER | 1 |
