| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EJ3891 | CLAMP ASSEMBLY | 4 | ||||
| ? | EJ3892 | ROD, THREADED | 1 | ||||
| ? | MM0176 | NUT, HEX - M6 X 1.00 | 2 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 4 | ||||
| ? | EK7164 | PLATE | 1 | ||||
| ? | MM0618 | CAPSCREW - M12 X 1.75 X 30 (ZINC) | 4 | ||||
| ? | MM0714 | FLAT WASHER - M12 (HARDENED) | 4 | ||||
| ? | MM0472 | LOCKWASHER - M12 | 4 | ||||
| ? | EG0655 | HARNESS, A/C COMPRESSOR JUMPER | 1 | ||||
| ? | 09842A0481 | PLATE, SAFETY - JUMP START ENGINE | 2 | ||||
| ? | EL4305 | HARNESS, ENGINE (EXTERNAL) | 1 | ||||
| ? | 443453211 | CLIP | 2 | ||||
| ? | 709530523 | CUSHION, HOSE | 2 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 2 | ||||
| ? | VH9969 | STUD, WELD - 3/8" - 16NC X 3/4" | 2 | ||||
| ? | C1547 | FLAT WASHER - 3/8" (PLAIN) | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 2 | ||||
| ? | HA2365 | HOSE | 1 | ||||
| ? | EG6272 | SHEET, BENT | 1 | ||||
| ? | MM0025 | CAPSCREW - M6 X 1.00 X 20 | 2 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 2 | ||||
| ? | EK7166 | RECEPTACLE | 1 | ||||
| ? | EK7677 | RECEPTACLE | 1 | ||||
| ? | VC8762 | CAPSCREW - 3/8" - 16NC X 1 1/2" | 8 | ||||
| ? | HE5611 | LOCKNUT - 3/8" - 16NC | 8 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 8 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 8 | ||||
| ? | PB5993 | COVER ASSEMBLY | 2 | ||||
| ? | PB5633 | TERMINAL, RING | 2 | ||||
| ? | VM3666 | TAG, PART NUMBER | 2 |
