| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VS7980 | GUARD, VALVE | 1 | ||||
| ? | STEM, VALVE (1) | 1 | |||||
| ? | TD7179 | CORE, VALVE | 1 | ||||
| ? | VE3880 | DYNASEAL (3) | 1 | ||||
| ? | VS7979 | NUT | 1 | ||||
| ? | BLADDER AND GAS VALVE ASSEMBLY (1)/(3) | 1 | |||||
| ? | TV9949 | RING, ANTI-EXTRUSION (2) | 1 | ||||
| ? | VE3903 | PLUG AND POPPET ASSEMBLY | 1 | ||||
| ? | TV9944 | • SPRING | 1 | ||||
| ? | VE3905 | • PLUG, BLEED | 1 | ||||
| ? | VE3908 | • O-RING | 1 | ||||
| ? | TV9948 | • NUT, STOP | 1 | ||||
| ? | VE3904 | • PLUG, MACHINED | 1 | ||||
| ? | TV9947 | • PISTON | 1 | ||||
| ? | TV9943 | • POPPET | 1 | ||||
| ? | VD4374 | SPACER (2) | 1 | ||||
| ? | VD4399 | LOCKNUT (2) | 1 | ||||
| ? | VE3907 | RING, BACKUP (2)/(3) | 1 | ||||
| ? | VD4373 | O-RING (2)/(3) | 1 | ||||
| ? | VE3906 | WASHER (2)/(3) | 1 | ||||
| ? | SHELL (1) | 1 | |||||
| ? | NOTE: (1) NOT SERVICED SEPARATELY. | ||||||
| ? | (2) INCLUDED IN VE3058 PORT ASSEMBLY. | ||||||
| ? | VE1715 | (3) INCLUDED IN VE1715 REPAIR KIT. |
