| Наименование | Страница | Код страницы |
|---|---|---|
| LIGHT ASSEMBLY (SUPER HALOGEN) | 238 | 41107 |
| LIGHT ASSEMBLY (SUPER HALOGEN) | 238 | 41107 |
| LIGHT ASSEMBLY (SUPER HALOGEN) | 238 | 41107 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | AK7526 | HEADLIGHT ASSEMBLY, LOW BEAM (SEE FIG 41107) | 2 | 41107 | |||
| ? | WA4513 | SCREW, SELF-TAPPING - #10 - 24NC X 1/2" | 24 | ||||
| ? | AK7525 | HEADLIGHT ASSEMBLY, HIGH BEAM (SEE FIG 41107) | 2 | 41107 | |||
| ? | TY7544 | COVER (1) | 2 | ||||
| ? | AK7524 | LIGHT, FOG (SEE FIG 41107) (2) | 2 | 41107 | |||
| ? | 07095-30213 | HOSE, CUSHION | 20 | ||||
| ? | 04434-51910 | CLIP | 20 | ||||
| ? | C1547 | FLAT WASHER - 3/8" (PLAIN) | 20 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 20 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 20 | ||||
| ? | EL4305 | HARNESS, ENGINE (EXTERNAL) | 1 | ||||
| ? | NOTE: (1) STANDARD EQUIPMENT. | ||||||
| ? | (2) OPTIONAL EQUIPMENT. |
