| Наименование | Страница | Код страницы |
|---|---|---|
| BATTERY CHARGING ALTERNATOR (XA3319) | 220 | 55767 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | MM0471 | LOCKWASHER - M10 | 21 | ||||
| ? | MM0648 | STUD, WELD - M10 X 1.50 X 25 | 2 | ||||
| ? | MM0713 | FLAT WASHER - M10 (HARDENED) (ZINC) | 2 | ||||
| ? | MM0178 | NUT, HEX - M10 X 1.50 | 2 | ||||
| ? | 443452711 | CLIP | 2 | ||||
| ? | 709530420 | CUSHION HOSE | 2 | ||||
| ? | TC1234 | CAPSCREW - 3/8" - 16NC X 3/4" (G5) (ZINC) | 11 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 19 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 19 | ||||
| ? | CH4027 | CABLE | 1 | ||||
| ? | XA3319 | ALTERNATOR, BATTERY CHARGING (SEE INDEX) | 1 | 55767 | |||
| ? | XA0117 | BELT, ALTERNATOR DRIVE | 1 | ||||
| ? | CH3850 | CABLE | 1 | ||||
| ? | PB9710 | SENSOR, COOLANT TEMPERATURE | 1 |
