| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE9591 | SPRING | 2 | ||||
| ? | VE9586 | SEAL (1) | 1 | ||||
| ? | VE9581 | RING, PISTON (1) | 1 | ||||
| ? | VE9578 | SLEEVE | 1 | ||||
| ? | VE9580 | RING, BACKUP (1) | 2 | ||||
| ? | VE9583 | SEAL, O-RING (1) | 1 | ||||
| ? | VE9585 | SEAL, O-RING (1) | 1 | ||||
| ? | VE9579 | PIN | 1 | ||||
| ? | VE9582 | RING, BACKUP (1) | 1 | ||||
| ? | VE9553 | BARREL, CYLINDER (3) | 1 | ||||
| ? | VE9577 | PISTON | 1 | ||||
| ? | VE9555 | BALL (3) | 1 | ||||
| ? | VE9554 | PISTON SHOE ASSEMBLY (3) | 9 | ||||
| ? | VE9574 | RING, RETAINER | 4 | ||||
| ? | VE9575 | WASHER | 2 | ||||
| ? | VE9573 | PIN | 2 | ||||
| ? | VE7572 | LINK | 1 | ||||
| ? | VE9584 | PIN | 1 | ||||
| ? | VE9564 | PIN, DOWEL | 2 | ||||
| ? | VE9559 | SADDLE | 1 | ||||
| ? | VE9539 | SEAL, O-RING (2) | 1 | ||||
| ? | VE9533 | PIN, ROLL | 1 | ||||
| ? | BF2617 | PIN, ROLL | 4 | ||||
| ? | BF2616 | BEARING | 2 | ||||
| ? | BF3176 | SWASH BLOCK (W/PIN) | 1 | ||||
| ? | VE9531 | BEARING, CYLINDER | 1 | ||||
| ? | VE9557 | RETAINER (3) | 1 | ||||
| ? | VE9556 | SPRING (3) | 9 | ||||
| ? | BF3727 | NOTE: (1) INCLUDED IN BF3727 CONTROL PISTON KIT. | |||||
| ? | BF1369 | (2) INCLUDED IN BF1369 HOUSING KIT. | |||||
| ? | (3) INCLUDED IN VE9552 ROTARY SUB-ASSEMBLY. |
