| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EK1677 | STEERING CYLINDER ASSEMBLY | 1 | ||||
| ? | PC0585 | • PISTON SEAL ASSEMBLY (1) | 1 | ||||
| ? | EK1679 | • ROD | 1 | ||||
| ? | PB9518 | • BEARING (1) | 1 | ||||
| ? | VL7694 | • LOCKNUT, NYLON - 1 3/4" (1) | 1 | ||||
| ? | VL7699 | • BEARING (1) | 1 | ||||
| ? | EH5932 | • PISTON | 1 | ||||
| ? | EH5933 | • HOUSING | 1 | ||||
| ? | SL8048 | • SEAL, O-RING (1) | 1 | ||||
| ? | WA1433 | • RING, BACKUP (1) | 1 | ||||
| ? | EC4589 | • GLAND | 1 | ||||
| ? | TD8516 | • CAPSCREW - 3/4" - 10NC X 3 1/4" G8 | 2 | ||||
| ? | PC0557 | • SEAL, ROD | 1 | ||||
| ? | PB8937 | • WIPER, ROD | 1 | ||||
| ? | TD7882 | • CAPSCREW - 3/4" - 10NC X 1 3/4" | 4 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 16 | ||||
| ? | PC0828 | BEARING, SPHERICAL | 2 | ||||
| ? | TY9714 | RETAINER | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 16 | ||||
| ? | AK4370 | NOTE: (1) INCLUDED IN AK4370 SEAL KIT. | |||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
