Номер на схеме	Каталожный номер	Название	Количество
?		TUBE, PITOT (1)/(2)	2
?	XA2279	PIN, DOWELL - REAR (3)	1
?	VE1297	FITTING, ORIFICE	1
?		PLATE, NAME (1)/(2)	1
?	XA2272	SHAFT & BRACKET	1
?	VE8126	RETAINER/SEAL ASSEMBLY (2)	1
?		SLEEVE, WEAR (1)/(2)	1
?	BF0884	BOLT	16
?	BF0848	WASHER, LOCK	16
?	BF0883	SEAL, OIL (2)	1
?	BF0842	RETAINER, BEARING	1
?	XA2277	SPACER, BEARING	1
?		SEAL, O-RING (1)/(2)	2
?	XA2273	BEARING, MAIN REAR (3)	1
?	BF0849	RING, SNAP (3)	1
?	VE8122	RING, EXTERNAL SNAP	1
?		RING, SEAL (1)/(2)	2
?	XA2336	BOLT	8
?	BF5366	WASHER, LOCK	8
?	XA2334	PULLEY, FAN	1
?	BF5359	ADAPTOR, PULLEY	1
?		RING, SEAL (1)/(2)	1
?	BF4032	PISTON	1
?		RING, SEAL (1)/(2)	1
?		WASHER, SPRING (1)	1
?		SHIM (1)/(2)	1
?	VE8128	RING, EXTERNAL SNAP (3)	1
?	VE8125	RING, EXTERNAL SNAP (3)	1
?	BF0885	HUB, SPLINED	1
?	VE1304	PLATE, CLUTCH (FACING) (3)	8
?		PLATE, CLUTCH (3)	8
?	VE8127	RING, INTERNAL SNAP (3)	1
?	XA2275	BEARING, MAIN FRONT (3)	1
?	VE8525	RETAINER, BEARING	1
?	BF0883	SEAL, OIL (2)	1
?		SLEEVE, WEAR (1)/(2)	1
?	VE8126	RETAINER/SEAL ASSEMBLY (2)	1
?	VE8123	BEARING, SLEEVE (3)	1
?	XA2274	HUB, FAN MOUNTING	1
?	XA2278	PIN, DOWEL - FRONT (3)	1
?	VE8524	BEARING, SLEEVE (3)	1
?	BF4043	CAP, END	1
?	XA2271	KIT, SEAL (3)	1
?		NOTE: (1) NOT SERVICED SEPARATELY.
?	XA2271	(2) INCLUDED IN XA2271 SEAL KIT.
?	EK2970	(3) INCLUDED IN EK2970 OVERHAUL KIT.
?		(TO ORDER FAN CLUTCH ASSEMBLY LESS PULLEY,
?		ORDER BF5364.)
