| Наименование | Страница | Код страницы |
|---|---|---|
| LIGHT ASSEMBLY (SUPER HALOGEN) | 304 | 41107 |
| LIGHT ASSEMBLY (SUPER HALOGEN) | 304 | 41107 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TC1234 | CAPSCREW - 3/8" - 16NC X 3/4" | 12 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 12 | ||||
| ? | EB4940 | BAR, TAPPED | 4 | ||||
| ? | ED1284 | HEAD LIGHT ASSEMBLY - R.H. | 1 | ||||
| ? | ED1285 | HEAD LIGHT ASSEMBLY - L.H. | 1 | ||||
| ? | AK3333 | HEAD LIGHT ASSEMBLY - LOW BEAM (SEE FIG 41107) | 2 | 41107 | |||
| ? | AK3332 | HEAD LIGHT ASSEMBLY - HIGH BEAM (SEE FIG 41107) | 2 | 41107 | |||
| ? | EB2165 | HOUSING, HEAD LIGHT | 2 | ||||
| ? | WA4513 | SCREW | 16 | ||||
| ? | EB2166 | COVER | 2 | ||||
| ? | VM1464 | MACHINE SCREW - #10 - 24NC X 5/8" | 12 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 12 | ||||
| ? | EF6855 | HARNESS | 1 | ||||
| ? | SG2103 | GROMMET, RUBBER | 2 | ||||
| ? | VN9907 | CLAMP | 8 | ||||
| ? | VH9969 | STUD, WELD - 3/8" - 16NC X 3/4" | 8 | ||||
| ? | DF3042 | FLAT WASHER - 3/8" | 8 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 8 | ||||
| ? | HARNESS, ENGINE (SEE ENGINE WIRING PG) | 1 | |||||
| ? | WA0192 | STUD, WELD - 1/4" - 20NC X 3/4" | 2 | ||||
| ? | SD5020 | LOCKWASHER - 1/4" | 2 | ||||
| ? | TD1549 | NUT - 1/4" - 20NC | 2 |
