| Наименование | Страница | Код страницы |
|---|---|---|
| LIGHT ASSEMBLY (SUPER HALOGEN) | 304 | 41107 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TZ0887 | CABLE - LEFT REAR | 1 | ||||
| ? | EJ5657 | HARNESS - RIGHT FRAME RAIL | 1 | ||||
| ? | TD1548 | CAPSCREW - 1/4" - 20NC X 5/8" | 2 | ||||
| ? | SP8417 | FLAT WASHER - 1/4" | 2 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 4 | ||||
| ? | TD1549 | NUT - 1/4" - 20NC | 4 | ||||
| ? | TZ6825 | BOX, JUNCTION | 1 | ||||
| ? | VZ2926 | GRIP, CORD | 3 | ||||
| ? | VM5587 | LOCKNUT, CONDULET | 3 | ||||
| ? | TZ0882 | CABLE - RIGHT REAR | 1 | ||||
| ? | SL7366 | GROMMET | 2 | ||||
| ? | AK8455 | REAR TURN & CLEARANCE LIGHTS (SEE FIG 41107) | 2 | 41107 | |||
| ? | EF9830 | MOUNTING, RIGHT CLEARANCE LIGHT | 1 | ||||
| ? | EF9831 | MOUNTING, LEFT CLEARANCE LIGHT | 1 | ||||
| ? | VM1464 | MACHINE SCREW - #10 - 24NC X 5/8" | 16 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 16 | ||||
| ? | TY9610 | WIRE | 2 | ||||
| ? | TY9173 | COVER | 2 | ||||
| ? | TC5943 | GROMMET | 2 |
