Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество
?	EF0993	PLATE, MOUNTING	1
?	TC1231	LOCKWASHER - 3/8"	10
?	TG5720	CAPSCREW - 3/8" - 16NC X 1"	10
?	TC1233	NUT - 3/8" - 16NC	8
?	TR1306	CAPSCREW - 1/4" - 20NC X 1"	4
?	EC1725	SWITCH, DISCONNECT	1
?	EF0994	GASKET	1
?	SP8417	FLAT WASHER - 1/4"	5
?	TD1549	NUT - 1/4" - 20NC	10
?	DC3584	LOCKWASHER - 1/4"	16
?	TR5445	LOCKWASHER - 1/2"	2
?	EF9013	BAR, BUS	1
?	TD1809	CAPSCREW - 1/4" - 20NC X 3/4"	7
?	TA7409	INSULATOR, STAND-OFF	2
?	EH7292	BAR, BUS	1
?	EG4485	WIRE	1
?	EG4483	WIRE	1
?	CH4306	CABLE	1
?	EC0442	BAR, BUS	1
?	VM1464	MACHINE SCREW - #10 - 24NC X 5/8"	10
?	DC3101	LOCKWASHER - #10	10
?	DF0017	NUT - #10 - 24NC	6
?	TZ0538	SPACER	2
?	PB0429	INSULATOR, STAND-OFF	2
?	EG4484	WIRE	1
?	PB8461	RELAY, POWER	1
?	TD1548	CAPSCREW - 1/4" - 20NC X 5/8"	4
?	EG4487	WIRE	1
?	EG4486	WIRE	1
?	EG4489	HOUSING	1
?	VZ3250	DIODE	1
?	PB6977	EQUALIZER, BATTERY	1
?	EH7295	BOX, BATTERY DISCONNECT SWITCH	1
?	EG4488	WIRE	1
?	VN7156	MACHINE SCREW - #12 - 24NC X 1"	2
?	DF3445	FLAT WASHER - #12	2
?	TR8580	NUT - #12 - 24NC	2
?	ED4418	BRACKET	1
?	PB8460	BREAKER, CIRCUIT	1
?	EC4311	INSULATOR, BUS BAR	2
?	SC5252	MACHINE SCREW - #8 - 32NC X 3/4"	4
?	VM9910	LOCKWASHER - #8	4
?	TF6248	FLAT WASHER - #8	4
?	TV2179	NUT - #8 - 32NC	4
?	ED0950	BAR, BUS	1
?		(NOT SOLD AS AN ASSEMBLY.
?		ORDER INDIVIDUAL COMPONENT PARTS.)
