| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EG1966 | HEATER, HYDRAULIC OIL | 2 | ||||
| ? | EG1968 | THERMOSTAT | 1 | ||||
| ? | HD8019 | BUSHING, PIPE | 1 | ||||
| ? | EG1972 | HARNESS, HYDRAULIC TANK HEATERS | 1 | ||||
| ? | EJ2096 | HARNESS (TO HOTSTART BOX) | 1 | ||||
| ? | VN9907 | CLAMP - 5/8" I.D. | 16 | ||||
| ? | VH9969 | STUD, WELD - 3/8" - 16NC X 3/4" | 15 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 15 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 15 | ||||
| ? | VZ1243 | GRIP, CORD | 1 | ||||
| ? | VM5588 | LOCKNUT - 3/4" | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | TZ2406 | PLATE, BENT | 2 | ||||
| ? | TG2568 | CLAMP - 7/8" I.D. | 6 |
