| Наименование | Страница | Код страницы |
|---|---|---|
| LIGHT ASSEMBLY (SUPER HALOGEN) - 1 | 332 | 40869 |
| LIGHT ASSEMBLY (SUPER HALOGEN) - 1 | 332 | 40869 |
| LIGHT ASSEMBLY (SUPER HALOGEN) - 1 | 332 | 40869 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | AK7508 | TAIL & STOP LIGHT ASSEMBLY (SEE FIG 40869) | 2 | 40869 | |||
| ? | SP8708 | LOCKWASHER - 3/8" | 6 | ||||
| ? | AK7506 | TURN/CLEARANCE LIGHT ASSEMBLY (SEE FIG 40869) | 2 | 40869 | |||
| ? | AK7503 | BACKUP LIGHT ASSEMBLY (SEE FIG 40869) | 2 | 40869 | |||
| ? | 424243 | CLAMP | 1 | ||||
| ? | VH9969 | STUD, WELD - 3/8" - 16NC X 3/4" | 5 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 9 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 9 | ||||
| ? | 720462 | CLAMP | 2 | ||||
| ? | 736131C2 | HORN, BACKUP | 2 | ||||
| ? | C5753 | CAPSCREW - 3/8" - 16NC X 4" | 4 | ||||
| ? | SP6153 | LOCKWASHER - 3/8" (EXTERNAL/INTERNAL TOOTH) | 2 | ||||
| ? | (NOT USED THIS APPLICATION) | ||||||
| ? | EJ5523 | HARNESS - REAR LIGHTS & BACKUP HORN | 1 | ||||
| ? | VN9907 | CLAMP | 1 | ||||
| ? | TG2562 | CLAMP | 1 | ||||
| ? | (NOT USED THIS APPLICATION) |
