| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | BF4323 | COOLER, FUEL | 1 | ||||
| ? | BF4325 | • FRAME, OIL COOLER | 1 | ||||
| ? | VE3999 | • GROMMENT, RUBBER | 18 | ||||
| ? | VE4000 | • GROMMENT, RUBBER | 18 | ||||
| ? | BF4326 | • TUBE | 18 | ||||
| ? | WB0473 | ADAPTOR, STRAIGHT | 3 | ||||
| ? | HA0913 | HOSE | 1 | ||||
| ? | HA1355 | HOSE | 1 | ||||
| ? | TR9441 | CLAMP | 11 | ||||
| ? | C5751 | CAPSCREW - 3/8" - 16NC X 2 1/2" | 5 | ||||
| ? | SD4572 | JAM NUT - 3/8" - 16NC (1) | 5 | ||||
| ? | C1547 | FLAT WASHER - 3/8" | 5 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 5 | ||||
| ? | C1521 | NUT - 3/8" | 5 | ||||
| ? | PC0315 | VALVE, DIVERTER | 1 | ||||
| ? | WB0273 | FITTING - 90 DEG | 2 | ||||
| ? | WB0320 | FITTING - 90 DEG | 1 | ||||
| ? | WB0364 | ADAPTOR | 1 | ||||
| ? | HA6156 | HOSE | 1 | ||||
| ? | HA5327 | HOSE | 1 | ||||
| ? | HA2389 | HOSE | 1 | ||||
| ? | WA4709 | CLAMP, HYDRA ZORB | 6 | ||||
| ? | WA4710 | CLAMP, HYDRA ZORB | 6 |
