| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | AK4082 | RIM - 57" X 32" | 1 | ||||
| ? | AK7754 | RING, FORGED - 1" X 6.5" | 1 | ||||
| ? | AK4085 | RING, FORGED - 1" X 4 3/4" | 1 | ||||
| ? | AK8010 | BAND, BEAD SEAT | 1 | ||||
| ? | AK8013 | RING, LOCK - 57" | 1 | ||||
| ? | PB6512 | O-RING | 1 | ||||
| ? | EF0701 | ADAPTOR, RING ASSEMBLY (OUTER) | 1 | ||||
| ? | EC9962 | • STUD, HEADED | 50 | ||||
| ? | ED4915 | • RING, ADAPTOR | 1 | ||||
| ? | TY2149 | FLAT WASHER (HARDENED) | 51 | ||||
| ? | WA5691 | CAPSCREW - 1 1/4" - 12UNF X 8 1/2" (12 PT) | 51 | ||||
| ? | EC9962 | STUD, HEADED | 50 | ||||
| ? | WA5657 | NUT, FLANGED - 1 1/2" - 12UNF | 100 | ||||
| ? | PB8882 | SPUD, DOUBLE | 1 | ||||
| ? | PB8881 | PLUG | 1 | ||||
| ? | PB8884 | EXTENSION, FLEXIBLE (INNER) | 1 | ||||
| ? | VJ8012 | HOUSING, CORE | 1 | ||||
| ? | WA2670 | CAP, VALVE | 1 | ||||
| ? | PB8883 | EXTENSION, FLEXIBLE (OUTER) | 1 | ||||
| ? | WA4649 | CLAMP | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 1 | ||||
| ? | C1547 | FLAT WASHER - 3/8" | 1 | ||||
| ? | C1601 | CAPSCREW - 3/8" - 16NC X 3/4" | 1 |
