Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
EF7076 |
HEATER/AIR CONDITIONER ASSM (SEE FIG 55110) |
1 |
|
55110 |
|
|
? |
MM0042 |
CAPSCREW - M10 X 1.50 X 25 |
14 |
|
|
|
|
? |
MM0461 |
FLAT WASHER - M10 |
14 |
|
|
|
|
? |
DA0557 |
WASHER |
3 |
|
|
|
|
? |
MM0471 |
LOCKWASHER - M10 |
14 |
|
|
|
|
? |
SM2109 |
SUPPORT |
1 |
|
|
|
|
? |
SM2106 |
PLENUM |
1 |
|
|
|
|
? |
PB7001 |
FILTER, AIR |
1 |
|
|
|
|
? |
TH0031 |
HOSE, HEATER |
2 |
|
|
|
|
? |
TG5601 |
FITTING, STRAIGHT - TO HEATER |
2 |
|
|
|
|
? |
SM2489 |
BLOCK, JUNCTION - REFRIGERANT |
1 |
|
|
|
|
? |
TV2642 |
ELBOW |
2 |
|
|
|
|
? |
SM2111 |
BRACKET |
1 |
|
|
|
|
? |
MM0026 |
CAPSCREW - M8 X 1.25 X 25 |
2 |
|
|
|
|
? |
MM0470 |
LOCKWASHER - M8 |
2 |
|
|
|
|
? |
EC8894 |
SEAL, NEOPRENE SPONGE |
2 |
|
|
|
|
? |
TY8687 |
SEAL, NEOPRENE SPONGE |
2 |
|
|
|
|
? |
EF7234 |
HOSE |
1 |
|
|
|
|
? |
EC8893 |
SEAL, NEOPRENE SPONGE |
2 |
|
|
|
|
? |
TY8684 |
SEAL, NEOPRENE SPONGE |
2 |
|
|
|
|
? |
VN6280 |
VALVE, SHUT-OFF |
2 |
|
|
|
|
? |
EF7235 |
HOSE |
1 |
|
|
|
|
? |
HC0908 |
CLAMP |
6 |
|
|
|
|
? |
MM0178 |
NUT - M10 X 1.50 |
1 |
|
|
|
|
? |
H3018 |
BUSHING, REDUCING |
2 |
|
|
|
|
? |
MM0042 |
CAPSCREW - M10 X 1.50 X 25 |
1 |
|
|
|
|
? |
MM0471 |
LOCKWASHER - M10 |
1 |
|
|
|
|
? |
VN9908 |
CLAMP |
1 |
|
|
|
|
? |
MM0641 |
WELD STUD - M8 X 20 |
3 |
|
|
|
|
? |
MM0460 |
FLAT WASHER - M8 |
3 |
|
|
|
|
? |
SM2318 |
VALVE, HEATER SOLENOID |
1 |
|
|
|
|
? |
PB8748 |
WELLNUT |
1 |
|
|
|
|
? |
H0596 |
CAPSCREW - 1/4" - 20NC X 1 1/4" |
2 |
|
|
|
|
? |
C1546 |
FLAT WASHER - 1/4" |
2 |
|
|
|
|
? |
C5774 |
LOCKWASHER - 1/4" |
2 |
|
|
|
|
? |
ED0560 |
HOSE, HEATER OUTLET |
1 |
|
|
|
|
? |
ED0561 |
HOSE, HEATER OUTLET |
1 |
|
|
|
|
? |
MM0177 |
NUT - M8 X 1.25 |
3 |
|
|
|
