| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SM1082 | INSTRUMENT PANEL, MOLDED | 1 | ||||
| ? | SM2840 | GAUGE MODULE | 1 | ||||
| ? | SM4358 | • PLATE, MOUNTING | 1 | ||||
| ? | EF6948 | • HARNESS - GAUGE PANEL | 1 | ||||
| ? | VH5017 | • STRAP, TIE | 5 | ||||
| ? | VZ5080 | • BULB | 6 | ||||
| ? | PB8551 | • GAUGE, OIL PRESSURE | 1 | ||||
| ? | PB6927 | • VOLTMETER | 1 | ||||
| ? | PB6982 | • INSERT, BLANK | 2 | ||||
| ? | PB7903 | • LOUVER, BALL | 1 | ||||
| ? | SM2785 | • HOURMETER | 1 | ||||
| ? | PB6926 | • GAUGE, FUEL LEVEL | 1 | ||||
| ? | PB6401 | • KIT, BEZEL OVERLAY | 1 | ||||
| ? | PB6303 | • GAUGE, WATER TEMPERATURE | 1 | ||||
| ? | SM2722 | • LEXAN OVERLAY, GAUGE MODULE | 1 | ||||
| ? | SM0926 | SCREW - M6 | 18 | ||||
| ? | PB8320 | ADAPTOR | 8 | ||||
| ? | PB8319 | LOUVER | 8 | ||||
| ? | SG2106 | SET SCREW - #6 - 32NC X 1/2" | 8 | ||||
| ? | PB6402 | KIT, BEZEL OVERLAY | 2 | ||||
| ? | PB6985 | SPEEDOMETER, DIGITAL - MPH | 1 | ||||
| ? | TY8743 | PANEL, BLANK INSERT | 1 | ||||
| ? | WA4605 | SCREW, PHILLIPS - #10 - 24NC X 1/2" | 2 | ||||
| ? | TW3834 | INDICATOR, HIGH BEAM | 1 | ||||
| ? | VZ5080 | BULB | 3 | ||||
| ? | TW5472 | INDICATOR, TURN | 2 | ||||
| ? | WA6639 | LEXAN OVERLAY, TURN SIGNAL | 1 | ||||
| ? | PB6984 | TACHOMETER - DIGITAL | 1 | ||||
| ? | PB8658 | SCREW - M6 X 1 | 2 | ||||
| ? | SM2841 | SWITCH MODULE | 1 | ||||
| ? | SM4359 | • PLATE, MOUNTING | 1 | ||||
| ? | PB7019 | • LIGHT, INDICATOR | 1 | ||||
| ? | VL6234 | • BULB | 1 | ||||
| ? | PB6972 | • SWITCH, ROCKER | 2 | ||||
| ? | EF9151 | • HARNESS - SWITCH MODULE | 1 | ||||
| ? | VH5017 | • STRAP, TIE | 5 | ||||
| ? | SM2729 | • LEXAN OVERLAY, SWITCH MODULE | 1 | ||||
| ? | PB7903 | • LOUVER, BALL | 1 | ||||
| ? | SM4422 | SWITCH/LIGHTS MODULE | 1 | ||||
| ? | SM4356 | • PLATE, MOUNTING | 1 | ||||
| ? | PB7019 | • LIGHT, INDICATOR | 1 | ||||
| ? | VL6234 | • BULB | 1 | ||||
| ? | SM2751 | • LEXAN OVERLAY - SWITCH/LIGHTS | 1 | ||||
| ? | PB6972 | • SWITCH, ROCKER | 3 | ||||
| ? | EF6950 | • HARNESS - SWITCH/LIGHTS PANEL | 1 | ||||
| ? | VH5017 | • STRAP, TIE | 5 | ||||
| ? | PB9752 | • SWITCH, ROCKER | 1 | ||||
| ? | VM7105 | • SWITCH, KEY | 1 | ||||
| ? | SM1088 | PLATE, R.H. RETAINER | 1 | ||||
| ? | TX7829 | SEAL, STEERING COLUMN | 1 | ||||
| ? | SM1086 | PLATE, L.H. RETAINER | 1 | ||||
| ? | SM2843 | WIPER SWITCH MODULE | 1 | ||||
| ? | SM4357 | • PLATE, MOUNTING | 1 | ||||
| ? | EF6949 | • HARNESS - WIPER DASH PANEL | 1 | ||||
| ? | VH5017 | • STRAP, TIE | 5 | ||||
| ? | TW5117 | • RHEOSTAT | 1 | ||||
| ? | PB0529 | • KNOB | 1 | ||||
| ? | TY9878 | • CONTROL, ELECTRIC WIPER | 1 | ||||
| ? | PB7026 | • SWITCH, ROCKER | 1 | ||||
| ? | PB6343 | • PLUG, BUTTON | 1 | ||||
| ? | PB7019 | • LIGHT, INDICATOR | 1 | ||||
| ? | VL6234 | • BULB | 1 | ||||
| ? | SM2754 | • LEXAN OVERLAY, SWITCH MODULE | 1 | ||||
| ? | SM2783 | HOSE | 2 | ||||
| ? | CC6103 | CLAMP | 4 | ||||
| ? | EF7748 | TUBE | 2 | ||||
| ? | LW02578 | ADHESIVE, SILICONE RUBBER | 1 | ||||
| ? | WA4513 | SCREW | 4 | ||||
| ? | PB9829 | SCREW, PANEL | 9 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | VS8192 | BOARD, TERMINAL (INSTL PANEL LIGHTS) | 1 | ||||
| ? | TG1929 | MACHINE SCREW - #10 - 24NC X 1/2" | 2 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 2 |
