| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HA5768 | HOSE - TO JUNCTION BLOCK | 2 | ||||
| ? | WB0538 | FITTING - 45 DEG. (AT JUNCTION BLOCK) | 2 | ||||
| ? | MM0641 | WELD STUD - M8 X 20 | 6 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 8 | ||||
| ? | MM0177 | NUT - M8 X 1.25 | 8 | ||||
| ? | TG2960 | CLAMP | 8 | ||||
| ? | EC1897 | TUBE | 1 | ||||
| ? | WA4704 | CLAMP | 9 | ||||
| ? | WA4703 | CLAMP | 1 | ||||
| ? | WB0418 | FITTING, TEE | 1 | ||||
| ? | EC1896 | TUBE | 1 | ||||
| ? | WB0581 | FITTING, STRAIGHT | 2 | ||||
| ? | TZ6006 | BLOCK, JUNCTION | 1 | ||||
| ? | C8558 | CAPSCREW - 3/8" - 16NC X 3 1/4" | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 2 | ||||
| ? | VW5169 | SPACER | 2 | ||||
| ? | HA5949 | HOSE | 1 | ||||
| ? | HA5944 | HOSE | 2 | ||||
| ? | WB0505 | FITTING - 90 DEG. | 1 | ||||
| ? | MM0051 | CAPSCREW - M8 X 1.25 X 50 | 2 | ||||
| ? | WB0374 | FITTING - 90 DEG. | 2 |
