| Наименование | Страница | Код страницы |
|---|---|---|
| INTERLOCK SWITCH (VE3530) | 426 | 64035 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VM0185 | COIL | 1 | ||||
| ? | VS9055 | RETAINER | |||||
| ? | VS9208 | SCREW - #10 - 32NF X 3/8" | 2 | ||||
| ? | VS9334 | BASE | 1 | ||||
| ? | VS9181 | SHIELD | 1 | ||||
| ? | VE5766 | SCREW - #6 X 3/8" | 2 | ||||
| ? | VS8940 | FRAME | 1 | ||||
| ? | VS9050 | SPACER | 1 | ||||
| ? | VS9210 | CAPSCREW - 1/4" - 20NC X 3/4" | 2 | ||||
| ? | VS8889 | CORE | 1 | ||||
| ? | VJ9163 | WASHER | 1 | ||||
| ? | VP9590 | SCREW / LOCKWASHER | 1 | ||||
| ? | VS9236 | STOP | 1 | ||||
| ? | DH5941 | CAPSCREW - 1/4" - 20NC X 5/8" | 2 | ||||
| ? | VS9230 | ARMATURE | 1 | ||||
| ? | VM0198 | SPRING | 1 | ||||
| ? | VS9368 | SCREW | 1 | ||||
| ? | VS9235 | ARM | 1 | ||||
| ? | VS7704 | BUSHING | 1 | ||||
| ? | VS9183 | PIN | 1 | ||||
| ? | VS9182 | BLOCK | 1 | ||||
| ? | VE5156 | SCREW - #10 - 20NC X 3/4" | 2 | ||||
| ? | VM0287 | SPRING (1) | 1 | ||||
| ? | VS9184 | SEAT (1) | 1 | ||||
| ? | VM0199 | TIP, CONTACT (1) | 1 | ||||
| ? | VM0283 | SHUNT | 1 | ||||
| ? | VM0282 | HORN | 1 | ||||
| ? | VN9544 | CAPSCREW - 1/4" - 20NC X 3/4" | 1 | ||||
| ? | DH5941 | SCREW - 1/4" - 20NC X 5/8" | 1 | ||||
| ? | VS8682 | COIL / SUPPORT | 1 | ||||
| ? | VS9393 | CORE | 1 | ||||
| ? | VJ9130 | TUBE | 1 | ||||
| ? | VJ9123 | HEAD | 1 | ||||
| ? | VS8913 | FLANGE | 1 | ||||
| ? | VS8911 | FLANGE | 1 | ||||
| ? | VS9209 | CAPSCREW - #10 - 32NF X 1/2 | 4 | ||||
| ? | VS8888 | SHIELD | 1 | ||||
| ? | 9414509 | CAPSCREW, WITH LOCKWASHER | 2 | ||||
| ? | TR4065 | CAPSCREW | 1 | ||||
| ? | VS8233 | SPACER | 1 | ||||
| ? | VM0199 | TIP CONTACT (1) | 1 | ||||
| ? | VN9544 | CAPSCREW | 1 | ||||
| ? | VS8875 | SIDE, L.H. | 1 | ||||
| ? | VS8874 | SIDE, R.H. | 1 | ||||
| ? | VP9573 | PIECE, POLE | 1 | ||||
| ? | VS9389 | PIECE, POLE | 1 | ||||
| ? | VS8275 | PIN | 2 | ||||
| ? | VJ8980 | SCREW | 4 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | VE3530 | SWITCH, INTERLOCK (SEE INDEX) | 1 | 64035 | |||
| ? | AK0943 | NOTE: (1) INCLUDED IN AK0943 CONTACT TIP KIT. | 1 |
