| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB8371 | DOUBLE FACED LIGHT ASSEMBLY | 1 | ||||
| ? | VE8105 | • LENS, CLEAR | 2 | ||||
| ? | VZ1912 | • BULB | 1 | ||||
| ? | VE8106 | • GASKET, LENS | 2 | ||||
| ? | VE5107 | CAPACITOR | 2 | ||||
| ? | TF6376 | MACHINE SCREW - #10 - 24NC X 1 1/4" | 2 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 2 | ||||
| ? | DF0017 | NUT - #10 - 24NC | 2 | ||||
| ? | VS8432 | BRACKET | 2 | ||||
| ? | TC4820 | MACHINE SCREW - #6 - 32NF | 2 | ||||
| ? | DF4944 | LOCKWASHER - #6 | 2 | ||||
| ? | HE5125 | FLAT WASHER - #6 | 2 | ||||
| ? | EC7253 | NAME PLATE - CAP1 | 1 | ||||
| ? | TZ7540 | NAME PLATE - GB2 | 1 | ||||
| ? | WB2367 | NAME PLATE - TB21 | 1 | ||||
| ? | EB7417 | BAR, BUS | 20 | ||||
| ? | WB2339 | STRIP, CIRCUIT ID | 1 | ||||
| ? | PB5732 | BOARD, TERMINAL | 3 | ||||
| ? | MM0206 | LOCKWASHER - M5 (INTERNAL TOOTH) | 6 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 6 | ||||
| ? | MM0373 | NUT - M5 | 6 | ||||
| ? | WB2338 | STRIP, CIRCUIT ID | 1 | ||||
| ? | WB2366 | NAME PLATE - TB20B | 1 | ||||
| ? | EB7418 | BAR, BUS | 1 | ||||
| ? | WB2337 | STRIP, CIRCUIT ID | 1 | ||||
| ? | WB2365 | NAME PLATE - TB20A | 1 | ||||
| ? | EC7254 | NAME PLATE - CAP2 | 1 | ||||
| ? | JG9371 | BUS, GROUND | 1 |
