Номер на схеме	Каталожный номер	Название	Количество
?	VE3828	SPOOLING SECTION ASSEMBLY	1
?	VJ1967	• CAP	1
?	VJ1962	• SPACER	1
?	VJ1975	• SNAP RING	1
?	VJ1972	• BALL	4
?	VJ1964	• PIN, DETENT	1
?	VJ1960	• SPRING	1
?	VE3823	• SPACER	1
?	VJ1957	• CAPSCREW	2
?	VE3820	• POPPET, CHECK VALVE	1
?	VE3826	• SPRING	1
?	VE3819	• O-RING	2
?	VE3818	• O-RING	2
?	VJ1947	• WIPER	2
?		• SPOOL (1)	1
?	VJ0012	• MACHINE SCREW	2
?	VJ1943	• PLATE, SEAL	2
?		• HOUSING, SPOOL (1)	1
?	VJ1944	• SEAT, SPRING	2
?	VJ1961	• SPRING	1
?	VJ1974	• BALL	1
?	VE3825	• SLEEVE, DETENT	1
?	VE3827	HOUSING, INLET	1
?	VE3829	HOUSING, OUTLET	1
?	VE3821	ROD, TIE	2
?	VJ1394	NUT	4
?	VE3822	ROD, TIE	1
?	VJ1933	NUT	2
?	VE3830	PLUG, SHUT-OFF ASSEMBLY	1
?	VE3979	VALVE, RELIEF	1
?		NOTE: (1) NOT SERVICED SEPARATELY.
