| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | MM0019 | CAPSCREW - M6 X 1.00 X 16 | 2 | ||||
| ? | MM0027 | CAPSCREW - M6 X 1.00 X 25 | 4 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 10 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 10 | ||||
| ? | MM0176 | NUT - M6 X 1.00 | 6 | ||||
| ? | PB1006 | LATCH/KEEPER SET | 1 | ||||
| ? | VZ2692 | LOCKNUT - CONDULET | 1 | ||||
| ? | CH2156 | CABLE - 7J1LS | 1 | ||||
| ? | CH2155 | CABLE - 7J1RS | 1 | ||||
| ? | CH2153 | CABLE - 7J1R | 1 | ||||
| ? | CH2158 | CABLE - 7J7 | 1 | ||||
| ? | CH2159 | CABLE - 7J8 | 1 | ||||
| ? | EB9886 | STUD | 1 | ||||
| ? | ED8936 | CLEAT, CABLE | 4 | ||||
| ? | TN2590 | HOSE, SPACER | 4 | ||||
| ? | VA0609 | SPACER | 3 | ||||
| ? | ED8937 | CLEAT, CABLE | 6 | ||||
| ? | MM0464 | FLAT WASHER - M16 | 2 | ||||
| ? | MM0474 | LOCKWASHER - M16 | 2 | ||||
| ? | MM0181 | NUT - M16 X 2.00 | 2 | ||||
| ? | CH2522 | CABLE - 7J4 | 1 | ||||
| ? | CH2592 | CABLE - 74 | 1 | ||||
| ? | CH2157 | CABLE - 7J1 | 1 | ||||
| ? | TV1748 | CAPSCREW - 5/8" - 11NC X 1 1/2" | 1 | ||||
| ? | VC1390 | LOCKWASHER - 5/8" | 2 | ||||
| ? | TR9082 | FLAT WASHER - 5/8" | 2 | ||||
| ? | TV1749 | NUT - 5/8" - 11NC | 1 | ||||
| ? | CH2151 | CABLE - 7J2 | 1 | ||||
| ? | CH2152 | CABLE - 7J10 (TO LEFT WHEEL MOTOR) | 1 | ||||
| ? | CH2154 | CABLE - 7J1L | 1 | ||||
| ? | CH2593 | CABLE - 71J | 1 | ||||
| ? | CH2595 | CABLE - 74AA | 1 | ||||
| ? | CH2596 | CABLE - 75X | 1 | ||||
| ? | CH2591 | CABLE - 71G | 1 | ||||
| ? | CH2594 | CABLE - 74D | 1 | ||||
| ? | CH2524 | CABLE - 7J9 | 1 | ||||
| ? | CH2160 | CABLE - 7GA2 | 1 | ||||
| ? | CH3123 | CABLE - 7GA1 | 1 | ||||
| ? | VM5587 | CONDULET, LOCKNUT | 1 | ||||
| ? | VG4399 | BUSHING, PLASTIC CONDULET | 1 | ||||
| ? | VM5736 | CORD, GRIP | 1 | ||||
| ? | EG0002 | HARNESS - ERR | 1 | ||||
| ? | TG2562 | CLAMP | 4 | ||||
| ? | ED3913 | CABLE, CONDUIT (WHEEL SPEED & TEMP SENSOR WIRING) | 1 | ||||
| ? | TG2568 | CLAMP | 1 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 4 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 4 | ||||
| ? | MM0176 | NUT - M6 X 1.00 | 4 | ||||
| ? | YA3199 | HARNESS - ALTERNATOR /ENGINE CONTROL | 1 | ||||
| ? | EF8496 | HARNESS - CAB/SYSTEM DIAGNOSTIC | 1 | ||||
| ? | EF8492 | HARNESS - BRAKE CABINET TO JCT. BOX | 1 | ||||
| ? | EF7368 | HARNESS - CUMMINS/INTERFACE | 1 | ||||
| ? | EF8488 | HARNESS - L.H. DECK | 1 | ||||
| ? | EF8487 | HARNESS - R.H. DECK | 1 | ||||
| ? | EF8498 | HARNESS - P2B3 CAB INTERFACE | 1 | ||||
| ? | EF8497 | HARNESS - P218 CAB INTERFACE | 1 | ||||
| ? | EG0008 | HARNESS - ACCUMULATOR PRESSURE SWITCH | 1 | ||||
| ? | EF7375 | HARNESS - R.H. FRAME RAIL | 1 | ||||
| ? | EF7374 | HARNESS - L.H. FRAME RAIL | 1 | ||||
| ? | EF8495 | HARNESS - P229 CAB POWER | 1 | ||||
| ? | EF8493 | PLATE, MOUNTING | 1 | ||||
| ? | EG0001 | HARNESS - CONT. CABINET TO CAB INTERFACE | 1 | ||||
| ? | EB6322 | BAR, BUS | 1 | ||||
| ? | VJ2296 | SHUNT | 2 | ||||
| ? | VM5737 | GRIP, CORD | 3 | ||||
| ? | C5769 | PLUG, PIPE | 1 | ||||
| ? | R2508 | TEE | 1 | ||||
| ? | TD9720 | ADAPTOR | 1 | ||||
| ? | VM4275 | HOSE | 1 | ||||
| ? | VY7326 | CONNECTOR, PIPE | 1 |
