| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EB8714 | CHANNEL | 1 | ||||
| ? | MM0593 | CAPSCREW - M8 X 1.25 X 20 | 8 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 8 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 8 | ||||
| ? | PB7490 | ARM BOW ASSEMBLY - R.H. | 1 | ||||
| ? | VE5449 | • BOW, ARM | 1 | ||||
| ? | C1603 | • CAPSCREW - 3/8" - 16NC X 1 1/4" (1) | 4 | ||||
| ? | VE5451 | • WASHER, FIBER - 25/64" x 7/8" (1) | 4 | ||||
| ? | H5304 | • LOCKWASHER - 3/8" (1) | 2 | ||||
| ? | SD4572 | • JAM NUT - 3/8" - 16NC (1) | 2 | ||||
| ? | VE5453 | • CLAMP (1) | 2 | ||||
| ? | VE5454 | • MOUNTING ANGLE (1) | 4 | ||||
| ? | VE5452 | • WASHER - 13/32" (1) | 2 | ||||
| ? | C1521 | • NUT - 3/8" - 16NC (1) | 2 | ||||
| ? | PB7491 | CONVEX MIRROR ASSEMBLY | 1 | ||||
| ? | VE5448 | • STRAP, MIRROR | 1 | ||||
| ? | VE5445 | • MIRROR, CONVEX GLASS | 1 | ||||
| ? | VE5447 | • TRIM, PINCHWELT | 1 | ||||
| ? | VE5446 | • SPRING, CLIP | 1 | ||||
| ? | VE5450 | NOTE: (1) INCLUDED IN VE5450 REPAIR KIT. |
