| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE9458 | ARMATURE ASSEMBLY | 1 | ||||
| ? | BF0097 | SHAFT | 1 | ||||
| ? | BF0998 | ARMATURE HEAD | 1 | ||||
| ? | VE4818 | PUNCHING, MAIN - 0.0185" | 256 | ||||
| ? | VE4819 | PUNCHING, END - 0.0673" | 4 | ||||
| ? | VE2761 | REWIND KIT, ARMATURE | 1 | ||||
| ? | BF1001 | PERMAFIL PUTTY | |||||
| ? | VE7206 | GLASS TAPE - 0.014" X 3/8" | 1 | ||||
| ? | VE4696 | LOCKWASHER - 5/16" | 6 | ||||
| ? | TR4731 | BOLT, HEX HEAD - 5/16" - 18NC X 1" | 6 | ||||
| ? | VS8884 | NUT, HEX - 1 11/16" - 16 | 1 | ||||
| ? | VS9031 | LOCKWASHER - 1 23/32" ID | 1 | ||||
| ? | H2982 | BALL BEARING | 1 | ||||
| ? | VS9032 | FLINGER, LUBRICANT | 1 | ||||
| ? | VS7492 | ADHESIVE, RTV SILMATE 1473 | |||||
| ? | VS9221 | BEARING CAP | 1 | ||||
| ? | BF1885 | FRAME HEAD | 1 | ||||
| ? | VE4257 | FAN | 1 | ||||
| ? | VS9062 | NUT - 1 1/8" - 18 | 1 | ||||
| ? | BF1889 | COTTER PIN | 1 | ||||
| ? | VS0961 | BALANCE WEIGHT | 1 | ||||
| ? | VE4687 | LOCKWASHER - 3/8" | 8 | ||||
| ? | VE4641 | BOLT - 3/8" - 16NC X 1 1/4" | 8 | ||||
| ? | C1630 | BOLT, HEX HEAD (SLOTTED) - 5/8" - 11NC X 2" | 16 | ||||
| ? | VC1390 | LOCKWASHER - 5/8" | 16 |
