Номер на схеме	Каталожный номер	Название	Количество
?	TY4432	BAR, BUS	1
?	TY4266	BAR, BUS	2
?	EB0747	BAR, BUS	2
?	TN4945	BAR, BUS	2
?	EC1077	BAR, BUS	2
?	TY4273	BAR, BUS	3
?	MM0022	CAPSCREW - M8 X 1.25 X 20	6
?	MM0460	FLAT WASHER - M8	6
?	MM0603	CAPSCREW - M10 X 1.50 X 16	4
?	MM0461	FLAT WASHER - M10	8
?	C1601	CAPSCREW - 3/8" - 16NC X 3/4"	8
?	C1547	FLAT WASHER - 3/8"	8
?	WB2058	DECAL, SCHEMATIC	1
?	EF8699	ENCLOSURE, CONTACTOR	1
?	EF8273	DOOR	1
?	EC1078	BAR, BUS	1
?	EG0025	HARNESS - 3 STEP ERR	1
?	EB1299	BAR, BUS	2
?	MM0621	CAPSCREW - M12 X 1.75 X 45	2
?	MM0472	LOCKWASHER - M12	28
?	MM0462	FLAT WASHER - M12	28
?	MM0179	NUT - M12 X 1.75	28
?	EC0191	CONDULET, BUSHING	2
?	WA5483	BUSHING, SNAP	1
?	EG1083	ENTRANCE	1
?	MM0580	CAPSCREW - M6 X 1.00 X 14	10
?	MM0469	LOCKWASHER - M6	10
?	VH5017	STRAP, TIE	27
?	MM0326	MACHINE SCREW - M3 X .5 X 6	4
?	EB9882	ARC BARRIER ASSEMBLY	5
?	EB9878	• BRACKET	10
?	EB9880	• SHEET	5
?	VC5344	• FLAT WASHER - #10	20
?	MM0373	• NUT - M5	20
?	EF9793	BRACKET ASSEMBLY	2
?	EC1120	• BRACKET	4
?	EF9791	• BRACKET	2
?	MM0459	• FLAT WASHER - M6	4
?	MM0176	• NUT - M6 X 1.00	4
?	MM0176	NUT - M6 X 1.00	4
?	VW6069	BOLT, INSULATED	6
?	VW6070	SHIELD	12
?	PB6200	ADAPTOR	3
?	PB4255	MODULE, SUPPRESSION	3
?	PB4265	ADAPTOR	3
?	WA3367	NUT	3
?	MM0619	CAPSCREW - M12 X 1.75 X 35	26
?	VJ9357	BAR, BUS	6
?	TY5603	BAR, BUS	7
?	PB5754	SPACER	3
?	PB6137	CONTACTOR	3
?	VJ0845	CONTACTOR	1
?	VE0996	SENSOR, POSITION	1
?	TY4272	INSULATOR	6
?	AK0938	NOTE: (1) AK0938 CONTACTOR TIP KIT (STANDARD).
?	AK0939	(2) AK0939 CONTACTOR TIP KIT (SILVER-TIP).
