| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VJ2178 | BEARING | 1 | ||||
| ? | VE3621 | HOUSING | 1 | ||||
| ? | VE3039 | BEARING CUP | 1 | ||||
| ? | VJ6365 | SPEED SENSOR HUB | 1 | ||||
| ? | VE4248 | GASKET | 1 | ||||
| ? | C1633 | C/S .62C X 2.75 G5 | 6 | ||||
| ? | VE5184 | FLAT WASHER | 6 | ||||
| ? | VE3041 | IMPELLER | 1 | ||||
| ? | VE3042 | IMPELLER | 1 | ||||
| ? | VE8377 | FAN, HOUSING | 1 | ||||
| ? | VE4247 | HEAD, FRAME | 1 | ||||
| ? | VE3638 | HUB, REAR | 1 | ||||
| ? | VJ0972 | MAGNETIC PICKUP | 1 | ||||
| ? | VE3620 | PIN | 2 | ||||
| ? | VJ8356 | CABLE ASSEMBLY | 1 | ||||
| ? | VS7922 | CONNECTOR | 1 | ||||
| ? | VE7272 | SEALANT | |||||
| ? | VE4639 | BUSING, REDUCING | 1 | ||||
| ? | VJ1028 | SUPPORT | 3 | ||||
| ? | BF3106 | KEY, 4" LONG | 3 | ||||
| ? | VJ1024 | BRUSH HOLDER | 3 | ||||
| ? | VE8444 | BRUSH, CARBON GE | 6 | ||||
| ? | C1631 | C/S .625C X .25 | 6 | ||||
| ? | VE4631 | FLAT WASHER | 6 | ||||
| ? | VJ7100 | C/S .62C X 1.75 G5 | 6 | ||||
| ? | VE5184 | FLAT WASHER | 21 | ||||
| ? | VE4998 | BOLT, HEX HEAD | 12 | ||||
| ? | VE4999 | BOLT, HEX HEAD | 12 | ||||
| ? | VE5185 | FLAT WASHER | 32 | ||||
| ? | VE4500 | BOLT, HEX HEAD | 26 | ||||
| ? | TC1233 | NUT, HEX | 12 | ||||
| ? | VS7492 | SEALER, .5 OZ | |||||
| ? | VE4997 | BAFFLE, AIR | 1 | ||||
| ? | VE5000 | BOLT, HEX SOC HEAD | 8 | ||||
| ? | VE3027 | WASHER | 38 | ||||
| ? | BF0930 | FAN HOUSING, FIRST STAGE | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | BF0931 | PANEL, AIR TEMPERATURE | 1 | ||||
| ? | VE5042 | BOARD, TERMINAL | 1 | ||||
| ? | BF0932 | SENSOR, THERM | 1 |
