| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB8056 | PANEL - DISPLAY EVENT | 1 | ||||
| ? | VE8168 | MODULE | 1 | ||||
| ? | VE8169 | RESISTOR - 1/8" WATT, 150 OHM | 6 | ||||
| ? | VE8170 | SWITCH ASSEMBLY | 3 | ||||
| ? | VE8171 | LED, GREEN | 2 | ||||
| ? | VE8172 | LED DISPLAY | 1 | ||||
| ? | VE8173 | RECEPTACLE WITH HARDWARE | 1 | ||||
| ? | VE8174 | BASE | 1 | ||||
| ? | VE8175 | COVER WITH STUD | 1 | ||||
| ? | (NOT USED THIS APPLICATION) | ||||||
| ? | BF3094 | WASHER - 5/32" X 5/16" X 5/16" | 4 | ||||
| ? | BF3095 | NUT - #6 - 32NC | 8 | ||||
| ? | VE5756 | FLAT WASHER - #6 | 4 | ||||
| ? | VE8178 | LOCKWASHER - #6 (INTERNAL TOOTH) | 4 | ||||
| ? | VE8992 | DECAL | 1 |
