| Наименование | Страница | Код страницы |
|---|---|---|
| AFSE PANEL COVER ASSEMBLY (VE5132) | 446 | 64038 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE5127 | PANEL BOX | 1 | ||||
| ? | VE5128 | HEAT SINK | 2 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | |||||
| ? | VE4902 | NUT, HEX - 1/4" - 20NC | 16 | ||||
| ? | C5746 | BOLT, HEX HEAD - 1/4" - 20NC X 3/4" | 5 | ||||
| ? | VE0299 | BUS BAR - 4.73" | 2 | ||||
| ? | VE5098 | SUPPORT | 2 | ||||
| ? | VE4382 | RECEPTACLE, LATCHING | 2 | ||||
| ? | VE4383 | SCREW - #4 - 40NC X 1/2" | 4 | ||||
| ? | VE4907 | FLAT WASHER - #4 | 4 | ||||
| ? | VE4908 | LOCKWASHER - #4 | 4 | ||||
| ? | VE4909 | NUT - #4 - 40NC | 4 | ||||
| ? | VE5132 | PANEL ASSEMBLY (SEE INDEX) | 1 | 64038 | |||
| ? | VE4911 | HINGE | 1 | ||||
| ? | VE4912 | MACHINE SCREW - #8 X 5/8" | 5 | ||||
| ? | VE4913 | MACHINE SCREW - #8 X 3/4" | 5 | ||||
| ? | VE4389 | SHIELD, INSULATION | 1 | ||||
| ? | VE4915 | MACHINE SCREW | 9 | ||||
| ? | VE2604 | BUS BAR | 1 | ||||
| ? | VE3217 | BUS BAR | 1 | ||||
| ? | VE4604 | FLAT WASHER - #8 | 15 | ||||
| ? | VE6320 | BOLT - 1/4" - 20NC X 1 1/8" | 2 | ||||
| ? | VE7202 | FLAT WASHER - 1/4" | |||||
| ? | TR1306 | BOLT, HEX HEAD - 1/4" - 20NC X 1" | 6 | ||||
| ? | VE0297 | BUS BAR WITH SCREWS | 2 | ||||
| ? | VE5310 | BUS BAR WITH SCREW | 1 | ||||
| ? | VE0302 | BUS BAR | 2 | ||||
| ? | VE0301 | BUS BAR | 2 |
