| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | REAR AXLE & SUSPENSION | ||||||
| ? | WA3108 | • PLATE, WARNING-HIGH VOLTAGE | 1 | ||||
| ? | • (FACE OF REAR AXLE DOOR) (1) | ||||||
| ? | TK7737 | • SEAL, REAR AXLE DOOR | 1 | ||||
| ? | TB2464 | • DECAL, WHEEL MOTOR (CHECK OIL LEVEL) | 1 | ||||
| ? | FRAME & FUEL TANK | ||||||
| ? | WA3103 | • PLATE, WARNING - RAISED BODY (FACE FUEL TANK) (1) | 1 | ||||
| ? | WA3102 | • PLATE, WARNING CLEARANCE REDUCED TURNING | 4 | ||||
| ? | • (FRAME BEHIND & FORWARD FRONT WHEEL) (2) | ||||||
| ? | WB2399 | • PLATE, SERIAL (FRAME FORWARD FRONT WHEEL) (2) | 1 | ||||
| ? | FRAME & HYDRAULIC TANK | ||||||
| ? | WA4328 | • PLATE DANGER - HIGH PRESSURE ACCUMULATOR | 2 | ||||
| ? | • (ON AND BY ACCUMULATOR) | ||||||
| ? | WA6629 | • PLATE, ATMOSPHERIC BREATHER SYSTEM | 1 | ||||
| ? | • (FACE OF HYDRAULIC TANK) (1) | ||||||
| ? | WA2998 | • PLATE, WARNING - HIGH PRESSURE HYD LINES | 1 | ||||
| ? | • (FACE OF HYDRAULIC TANK) (1) | ||||||
| ? | WA6628 | • DECAL, CAUTION - ADD OIL HYD TANK (SIDE HYD TANK) | 1 | ||||
| ? | WA8890 | • DECAL, EMERGENCY DUMP PROCEDURE | 1 | ||||
| ? | • • (ON TOP SIDE OF CENTER CROSS TUBE ON LEFT SIDE) | ||||||
| ? | WA8889 | • DECAL, (EMERGENCY STEERING PROCEDURE - L.H. FRAME) | 2 | ||||
| ? | • (AT STEERING MANIFOLD) | ||||||
| ? | WA2892 | • PLATE, DANGER (ON SUSPENSION CYLINDER & | 4 | ||||
| ? | • STEERING ACCUMULATOR) | ||||||
| ? | WA3103 | • PLATE, WARNING - FACE OF HYD. TANK (2) | 1 | ||||
| ? | NOTE: (1) USE DC9822 DRIVE SCREW AS REQUIRED. | ||||||
| ? | (2) USE R1073 DRIVE SCREW AS REQUIRED. | ||||||
| ? | (SEE FOLLOWING PAGE FOR BALANCE OF PARTS...) |
