| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE3530 | INTERLOCK | 1 | ||||
| ? | BF0018 | BOX | 1 | ||||
| ? | VE1142 | PIN - 1/16" X 3/8" | 2 | ||||
| ? | VE1142 | PIN - 1/16" X 3/8" | 1 | ||||
| ? | VE0995 | INNER ARM ASSEMBLY | 1 | ||||
| ? | VE0375 | SPRING | 1 | ||||
| ? | VE5751 | MACHINE SCREW - #4 - 40NC X 5/8" | 1 | ||||
| ? | VE4908 | LOCKWASHER - #4 | 1 | ||||
| ? | VE4909 | NUT - #4 - 40NC | 1 | ||||
| ? | VE1143 | SPRING | 1 | ||||
| ? | VE4405 | STUD ASSEMBLY | 1 | ||||
| ? | VE4406 | STUD ASSEMBLY | 1 | ||||
| ? | VE5752 | STUD - TAPPED | 1 | ||||
| ? | VE5753 | MACHINE SCREW - #4 - 40NC X 1/4" | 1 | ||||
| ? | VE4908 | LOCKWASHER - #4 | 1 | ||||
| ? | VE4907 | FLAT WASHER - #6 | 1 | ||||
| ? | BF0020 | SCREW, SL PAN HEAD (SPECIAL) | 5 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 5 | ||||
| ? | HE5125 | FLAT WASHER - #6 | 5 | ||||
| ? | VE5757 | OUTER ARM ASSEMBLY | 1 | ||||
| ? | SF2755 | NUT, HEX - #10 - 32NF | 3 | ||||
| ? | VC1390 | LOCKWASHER - 5/8" | 3 | ||||
| ? | VS6662 | FLAT WASHER - #10 | 3 | ||||
| ? | BF3174 | COVER | 1 |
