| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VS7677 | INTERLOCK | 1 | ||||
| ? | VE5880 | FINGER, CONTACT | 2 | ||||
| ? | VE4921 | MACHINE SCREW - #10 - 32NF X 1" | 2 | ||||
| ? | VS9029 | FINGER SUPPORT - 3.50" | 1 | ||||
| ? | VS9388 | WASHER, CUP | 5 | ||||
| ? | VS6662 | FLAT WASHER - #10 | 14 | ||||
| ? | VS9057 | SPRING POST | 2 | ||||
| ? | VE5881 | COTTER PIN - 0.062" X 1/2" | 2 | ||||
| ? | VE5882 | BOLT, HEX HEAD - 1/4" - 20NC X 7/8" | 2 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 2 | ||||
| ? | TD1549 | NUT, HEX - 1/4" - 20NC (ZINC PL) | 2 | ||||
| ? | VM0219 | SPRING | 2 | ||||
| ? | VS8164 | SEAT | 4 | ||||
| ? | VM0284 | SCREW, CONTACT | 4 | ||||
| ? | VC1390 | LOCKWASHER - 5/8" | 14 | ||||
| ? | SF2755 | NUT, HEX - #10 - 32NF (ZINC PL) | 16 | ||||
| ? | VE5883 | PLATE | 1 | ||||
| ? | VS6662 | FLAT WASHER - #10 | 3 | ||||
| ? | VC1390 | LOCKWASHER - 5/8" | 3 | ||||
| ? | SF2755 | NUT, HEX - #10 - 32NF (ZINC PL) | 3 | ||||
| ? | VE4086 | SUPPORT, CONTACT | 1 | ||||
| ? | VE5884 | MACHINE SCREW - #10 - 32NF X 3/4" | 3 | ||||
| ? | VE7202 | FLAT WASHER - 1/4" | 1 |
