Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
PB8040 |
PANEL PLUG KIT - SSIII |
1 |
|
|
|
|
? |
EC4862 |
SLEEVE, INSULATING |
4 |
|
|
|
|
? |
EC2721 |
NAME PLATE - CN A |
1 |
|
|
|
|
? |
EC2722 |
NAME PLATE - CN B |
1 |
|
|
|
|
? |
EC2723 |
NAME PLATE - CN C |
1 |
|
|
|
|
? |
EC7251 |
NAME PLATE - CN D |
1 |
|
|
|
|
? |
EC7252 |
NAME PLATE - CN E |
1 |
|
|
|
|
? |
SR8325 |
SWITCH, TOGGLE |
2 |
|
|
|
|
? |
EC7461 |
NAME PLATE - DL6 |
1 |
|
|
|
|
? |
VF6697 |
INDICATOR, HIGH BEAM |
1 |
|
|
|
|
? |
VL6234 |
• LAMP, MINIATURE |
1 |
|
|
|
|
? |
VS0035 |
DOME LIGHT |
2 |
|
|
|
|
? |
VZ1912 |
• BULB |
2 |
|
|
|
|
? |
TM9090 |
• INSULATOR |
2 |
|
|
|
|
? |
DC3101 |
LOCKWASHER - #10 |
18 |
|
|
|
|
? |
TG1929 |
MACHINE SCREW - #10 - 24NC X 1/2" |
10 |
|
|
|
|
? |
EB7403 |
NAME PLATE - TB21H |
1 |
|
|
|
|
? |
PB8056 |
PANEL, DISPLAY EVENT SS III |
1 |
|
|
|
|
? |
ED3404 |
BRACKET, BENT |
1 |
|
|
|
|
? |
MM0176 |
NUT - M6 X 1.00 |
14 |
|
|
|
|
? |
MM0459 |
FLAT WASHER - M6 |
21 |
|
|
|
|
? |
MM0469 |
LOCKWASHER - M6 |
14 |
|
|
|
|
? |
VS8193 |
BOARD, TERMINAL |
1 |
|
|
|
|
? |
MM0206 |
LOCKWASHER - M5 |
7 |
|
|
|
|
? |
MM0373 |
NUT - M5 |
7 |
|
|
|
|
? |
ED6897 |
NAME PLATE - TB21J |
1 |
|
|
|
|
? |
VM2951 |
SET SCREW - #6 - 32NC X 5/16" |
2 |
|
|
|
|
? |
WB2094 |
STRIP, CIRCUIT I.D. |
1 |
|
|
|
|
? |
VS8479 |
BOARD, TERMINAL |
1 |
|
|
|
|
? |
PB8946 |
STATEX III CONTROL CABINET (SEE INDEX) |
1 |
|
64064 |
|
|
? |
MM0378 |
LOCKWASHER - M4 (EXTERNAL TOOTH) |
12 |
|
|
|
|
? |
TZ7521 |
NAME PLATE - PLCP |
1 |
|
|
|
|
? |
EC7256 |
NAME PLATE - ST 2 |
1 |
|
|
|
|
? |
MM0372 |
NUT - M4 |
8 |
|
|
|
|
? |
EF5554 |
TRANSFORMER, ALT SYNC |
2 |
|
|
|
|
? |
ED2918 |
BRACKET, MOUNTING |
1 |
|
|
|
|
? |
30481R1 |
FLAT WASHER - M5 |
4 |
|
|
|
|
? |
TZ7542 |
NAME PLATE - GB3 |
1 |
|
|
|
|
? |
VC5344 |
FLAT WASHER - #10 |
16 |
|
|
|
|
? |
SD5369 |
MACHINE SCREW |
4 |
|
|
|
|
? |
PB5587 |
MODULAR |
1 |
|
|
|
|
? |
TZ7527 |
NAME PLATE - CPR |
1 |
|
|
|
|
? |
SD4245 |
LOCKWASHER - #10 (EXTERNAL TOOTH) |
4 |
|
|
|
|
? |
DF0017 |
NUT - #10 - 24NC |
8 |
|
|
|
|
? |
PB4255 |
MODULE, SUPPRESSION |
2 |
|
|
|
|
? |
VG7043 |
RELAY |
2 |
|
|
|
|
? |
WA3597 |
NUT |
4 |
|
|
|
|
? |
DL9148 |
BAR, BUS |
4 |
|
|
|
|
? |
EC7258 |
NAME PLATE - CPD1 |
1 |
|
|
|
|
? |
EC7466 |
NAME PLATE - TJ1L |
1 |
|
|
|
|
? |
EC7259 |
NAME PLATE - CPD2 |
1 |
|
|
|
|
? |
EC7457 |
NAME PLATE - DL5 |
1 |
|
|
|
|
? |
EC7255 |
NAME PLATE - ST1 |
1 |
|
|
|
|
? |
VG6991 |
MACHINE SCREW - #8 - 24NC X 1" |
2 |
|
|
|
|
? |
TF6248 |
FLAT WASHER - #8 |
2 |
|
|
|
|
? |
VM9910 |
LOCKWASHER - #8 |
2 |
|
|
|
|
? |
PB7591 |
BLOCK, TERMINAL |
1 |
|
|
|
|
? |
WB2078 |
DECAL, SWITCH |
1 |
|
|
|
