Каталог Komatsu

Номер на схеме	Каталожный номер	Название	Количество
?	VE6119	PANEL, RESISTOR (SEE INDEX)	1	64096
?	MM0460	FLAT WASHER - M8	12
?	MM0470	LOCKWASHER - M8	12
?	MM0177	NUT - M8 X 1.25	12
?	TZ7513	NAME PLATE - AFSE	1
?	VS0035	DOME LIGHT	1
?	VZ1912	• BULB	2
?	TM9090	• INSULATOR	2
?	DC3101	LOCKWASHER - #10	3
?	TG1929	MACHINE SCREW - #10 - 24NC X 1/2"	3
?	ED6878	GASKET	4
?	PB8838	STATIC EXCITER, ALT FIELD (SEE INDEX)	1	64071A
?	PB8837	STATIC EXCITER, MOTOR FIELD (SEE INDEX)	1	64073
?	ED0373	NAME PLATE - 74C	1
?	ED0374	NAME PLATE - 74F	1
?	ED0368	NAME PLATE - 7J14	1
?	TZ7516	NAME PLATE - CT	1
?	PB7875	RESISTOR	1
?	MM0459	FLAT WASHER - M6	8
?	MM0378	LOCKWASHER, EXTERNAL TOOTH - M4	8
?	MM0372	NUT - M4	8
?	PB5230	RESISTOR	1
?	EC2026	HOUSING - CURRENT TRANSFORMER RESISTOR	1
?	TK7659	RESISTOR	1
?	VJ9204	TRANSFORMER, RIPPLE	1
?	VE6113	PANEL	1
?	PB4262	TRANSFORMER, CURRENT	1
?	MM0027	CAPSCREW - M6 X 1.00 X 25	2
?	MM0469	LOCKWASHER - M6	2
?	EC7257	NAME PLATE - CTR	1
?	ED0361	NAME PLATE - 71G	1
?	ED0362	NAME PLATE - 74D	1
?	ED0363	NAME PLATE - 7J9	1
?	EC7460	NAME PLATE - DL4	1
?	ED0359	NAME PLATE - 74AA	3
?	TZ7543	NAME PLATE - R1	1
?	ED0358	NAME PLATE - 71J	2
?	ED0372	NAME PLATE - 74E	1
?	ED0360	NAME PLATE - 75X	2
?	ED0370	NAME PLATE - 7J13	1
?	ED0369	NAME PLATE - 71K	1
?	TZ7514	NAME PLATE - MFSE	1

?
