| Наименование | Страница | Код страницы |
|---|---|---|
| PAYLOAD LIGHT ASSEMBLY | 350 | 55096 |
| PAYLOAD LIGHT ASSEMBLY | 350 | 55096 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EF9757 | HARNESS, PAYLOAD METER | 1 | ||||
| ? | EF8488 | HARNESS - LEFT DECK | 1 | ||||
| ? | EF8487 | HARNESS - RIGHT DECK | 1 | ||||
| ? | WA4887 | CLAMP | 4 | ||||
| ? | VG7146 | CAPSCREW - 1/2" - 13NC X 3/4" | 8 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 8 | ||||
| ? | TR6008 | FLAT WASHER - 1/2" | 8 | ||||
| ? | EF8679 | LOAD WEIGH VALVE ASSEMBLY | 4 | ||||
| ? | TZ8627 | • VALVE, BODY | 4 | ||||
| ? | TD7179 | • CORE, VALVE | 4 | ||||
| ? | EF8677 | • ADAPTOR, TRANSDUCER | 4 | ||||
| ? | 070051009 | • O-RING | 4 | ||||
| ? | EF8669 | SENSOR, PRESSURE | 4 | ||||
| ? | COVER (TO BE SUPPLIED LATER) | 2 | |||||
| ? | TC1234 | CAPSCREW - 3/8" - 16NC X 3/4" | 4 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 4 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 4 | ||||
| ? | EB3789 | LIGHT HOUSING ASSM - R.H. (SEE FIG 55096) | 1 | 55096 | |||
| ? | EF9163 | LIGHT HOUSING ASSM - L.H. (SEE FIG 55096) | 1 | 55096 |
