| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WA4852 | FITTING | 1 | ||||
| ? | WA4855 | ELBOW - 90 DEG | 1 | ||||
| ? | TW2409 | HYDRAULIC PUMP ASSM (REWORK) | 1 | ||||
| ? | PB4104 | • PUMP, HYDRAULIC | 1 | ||||
| ? | RK1022 | • • KIT, SEAL | 1 | ||||
| ? | TW0277 | GASKET | 1 | ||||
| ? | 820365 | STUD - 3/8" - 16NC X 2" | 2 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | |||||
| ? | TW0279 | ELBOW | 1 | ||||
| ? | TW0278 | TUBE, NYLON | 1 | ||||
| ? | HA6581 | HOSE - SUPPLY FROM HYD. TANK | 1 | ||||
| ? | C1603 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 4 | ||||
| ? | VG9097 | SEAL, O-RING | 2 | ||||
| ? | TF8077 | CLAMP, SPLIT FLANGE | 2 | ||||
| ? | C1614 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 4 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 15 | ||||
| ? | VG9095 | SEAL, O-RING | 2 | ||||
| ? | TF8090 | CLAMP, SPLIT FLANGE | 2 | ||||
| ? | WA2220 | WELD STUD - 1/2" - 13NC X 1" | 12 | ||||
| ? | C1523 | NUT - 1/2" - 13NC | 11 | ||||
| ? | HA6343 | HOSE | 1 | ||||
| ? | TR9441 | CLAMP | 6 |
