Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
EC1207 |
MANIFOLD |
1 |
|
|
|
|
? |
H5303 |
CAPSCREW - 1/2" - 13NC X 5 1/4" |
2 |
|
|
|
|
? |
WA4728 |
FLAT WASHER - 1/2" |
2 |
|
|
|
|
? |
C1540 |
LOCKWASHER - 1/2" |
26 |
|
|
|
|
? |
C1523 |
NUT - 1/2" - 13NC |
2 |
|
|
|
|
? |
TF3231 |
FLANGE, SPLIT |
6 |
|
|
|
|
? |
WA0187 |
SEAL, O-RING |
4 |
|
|
|
|
? |
C1614 |
CAPSCREW - 1/2" - 13NC X 1 1/2" |
20 |
|
|
|
|
? |
EC1205 |
ANGLE |
1 |
|
|
|
|
? |
WA5460 |
CLAMP |
1 |
|
|
|
|
? |
EC1210 |
TUBE |
1 |
|
|
|
|
? |
VH6718 |
FLANGE, SPLIT |
2 |
|
|
|
|
? |
WA0232 |
SEAL, O-RING |
1 |
|
|
|
|
? |
C1615 |
CAPSCREW - 1/2" - 13NC X 1 3/4" |
4 |
|
|
|
|
? |
EC1208 |
TUBE |
1 |
|
|
|
|
? |
EB8744 |
BRACKET, PUMP |
1 |
|
|
|
|
? |
C1663 |
CAPSCREW - 7/8" - 9NC X 3" |
3 |
|
|
|
|
? |
C1543 |
LOCKWASHER - 7/8" |
3 |
|
|
|
|
? |
WA0363 |
FLAT WASHER - 7/8" (HARDENED) |
3 |
|
|
|
|
? |
C1529 |
NUT - 7/8" - 9NC |
3 |
|
|
|
|
? |
PB7980 |
CHECK VALVE, ORIFICE |
1 |
|
|
|
|
? |
C5760 |
CAPSCREW - 1/2" - 13NC X 5 1/2" |
4 |
|
|
|
|
? |
HA7474 |
HOSE |
1 |
|
|
|
|
? |
EC1209 |
TUBE |
1 |
|
|
|
|
? |
WA4712 |
CLAMP, HYDRA ZORB |
1 |
|
|
|
|
? |
TF8090 |
FLANGE, SPLIT |
4 |
|
|
|
|
? |
VG9095 |
SEAL, O-RING |
2 |
|
|
|
|
? |
WB0993 |
SWIVEL FLANGE/SPLIT FLANGE |
1 |
|
|
|
|
? |
PB6528 |
COUPLING, DIAGNOSTIC |
3 |
|
|
|
|
? |
PB6041 |
CAP, DUST |
3 |
|
|
|
|
? |
PB8267 |
HOIST VALVE ASSEMBLY (SEE INDEX) |
1 |
|
55008 |
|
|
? |
EF5500 |
HOIST PUMP INSTALLATION (SEE INDEX) |
1 |
|
40251 |
|
|
? |
MM0086 |
CAPSCREW - M16 X 2.00 X 60 |
6 |
|
|
|
|
? |
MM0474 |
LOCKWASHER - M16 |
6 |
|
|
|
|
? |
MM0706 |
FLAT WASHER - M16 (HARDENED) |
12 |
|
|
|
|
? |
MM0181 |
NUT - M16 X 2.00 |
6 |
|
|
|
