| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EF8397 | HOIST CYLINDER ASSM (SEE INDEX) | 2 | 55043 | |||
| ? | PB9977 | UNLOADER VALVE ASSM (SEE INDEX) | 1 | 55114 | |||
| ? | HA7430 | HOSE | 1 | ||||
| ? | HA4522 | HOSE | 1 | ||||
| ? | HA7340 | HOSE | 1 | ||||
| ? | HA7392 | HOSE | 1 | ||||
| ? | EF8389 | HYDRAULIC TANK ASSM (SEE FIG 55141) | 1 | 55141 | |||
| ? | WB0508 | FITTING - 90 DEG | 2 | ||||
| ? | TG2568 | CLAMP | 3 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 1 | ||||
| ? | WA0720 | FLAT WASHER - 3/8" | 3 | ||||
| ? | PC0184 | DRIVE SHAFT ASSEMBLY (SEE FIG 55350) | 1 | 55350 | |||
| ? | HA6502 | HOSE | 3 | ||||
| ? | HA7339 | HOSE | 1 | ||||
| ? | EF7580 | HOIST PUMP MODULE (SEE INDEX) | 1 | 55002 | |||
| ? | HA6240 | HOSE | 2 | ||||
| ? | HA7431 | HOSE | 2 | ||||
| ? | TF3231 | CLAMP, SPLIT FLANGE | 6 | ||||
| ? | WA0187 | SEAL, O-RING | 3 | ||||
| ? | C1614 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 12 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 16 | ||||
| ? | PB9715 | HI-PRESSURE FILTER ASSM (SEE INDEX) | 1 | 55053 | |||
| ? | WB0996 | SWIVEL FLANGE/SPLIT FLANGE | 1 | ||||
| ? | C1629 | CAPSCREW - 5/8" - 11NC X 1 3/4" | 4 | ||||
| ? | C1541 | LOCKWASHER - 5/8" | 8 | ||||
| ? | VL9963 | CLAMP, SPLIT FLANGE | 4 | ||||
| ? | WA0237 | SEAL, O-RING | 2 | ||||
| ? | WA4897 | FITTING, STRAIGHT ADAPTOR | 1 | ||||
| ? | WB0601 | FITTING, STRAIGHT ADAPTOR | 1 | ||||
| ? | C1638 | CAPSCREW - 5/8" - 11NC X 4" | 4 | ||||
| ? | VG6718 | CLAMP, SPLIT FLANGE | 2 | ||||
| ? | WB0297 | FITTING - 45 DEG | 1 | ||||
| ? | C1640 | CAPSCREW - 5/8" - 11NC X 4 1/4" | 4 | ||||
| ? | PB9770 | VALVE, SHUT-OFF | 1 | ||||
| ? | WA0232 | SEAL, O-RING | 2 | ||||
| ? | PB9769 | VALVE, SHUT-OFF | 1 | ||||
| ? | VM0319 | PLUG, O-RING | 1 | ||||
| ? | WB0582 | FITTING, STRAIGHT ADAPTOR | 1 | ||||
| ? | WB0690 | FITTING, STRAIGHT ADAPTOR | 1 | ||||
| ? | WB0561 | TEE | 1 | ||||
| ? | HA7454 | HOSE | 1 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 1 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 1 | ||||
| ? | WA0237 | SEAL, O-RING | 1 | ||||
| ? | HA7332 | HOSE - TO BRAKE RETURN AT BRAKE CABINET | 1 | ||||
| ? | TH5601 | CLAMP, HALF | 1 | ||||
| ? | TH5602 | GROMMET | 1 | ||||
| ? | C7591 | CAPSCREW - 1/4" - 20NC X 2" | 2 | ||||
| ? | C5774 | LOCKWASHER - 1/4" | 2 | ||||
| ? | EG1215 | PLATE | 1 |
