| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | C7588 | CAPSCREW - 1/4" - 20NC X 1" | 4 | ||||
| ? | C5774 | LOCKWASHER - 1/4" | 8 | ||||
| ? | C1546 | FLAT WASHER - 1/4" | 8 | ||||
| ? | VN9751 | LOCKNUT - 1/4" - 20NC | 4 | ||||
| ? | VL6217 | SWITCH, MAGNETIC | 2 | ||||
| ? | EF8721 | BRACKET, SOLENOID | 1 | ||||
| ? | VZ0589 | SWITCH, PRESSURE | 1 | ||||
| ? | PB8726 | MOTOR, CRANKING - 24 VOLT | 2 | ||||
| ? | C1629 | CAPSCREW - 5/8" - 11NC X 1 3/4" | 6 | ||||
| ? | C1541 | LOCKWASHER - 5/8" | 10 | ||||
| ? | CH2717 | CABLE, BATTERY | 1 | ||||
| ? | CH2716 | CABLE, BATTERY | 1 | ||||
| ? | EC4419 | CABLE, RH STARTER | 1 | ||||
| ? | CH2724 | CABLE, GROUND | 1 | ||||
| ? | CH2924 | CABLE, BATTERY CHARGING ALTERNATOR | 1 | ||||
| ? | VN9907 | CLAMP | 2 | ||||
| ? | TC6058 | CLAMP | 2 | ||||
| ? | VC7674 | CLAMP | 2 | ||||
| ? | MM0641 | STUD WELD - M8 X 20 | 2 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 5 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 5 | ||||
| ? | MM0177 | NUT - M8 X 1.25 | 5 | ||||
| ? | TF6924 | CLAMP | 6 |
