Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
CH2722 |
CABLE, BATTERY |
1 |
|
|
|
|
? |
VZ0852 |
BATTERY |
4 |
|
|
|
|
? |
EG3571 |
BATTERY BOX ASSEMBLY - L.H. |
1 |
|
|
|
|
? |
CH3408 |
CABLE, BATTERY |
1 |
|
|
|
|
? |
PB9181 |
CABLE, BATTERY TAP OFF |
1 |
|
|
|
|
? |
EC4410 |
CABLE, BATTERY - L.H. |
1 |
|
|
|
|
? |
EF8478 |
BATTERY EQUALIZER BOX ASSM (SEE FIG 55236) |
1 |
|
55236 |
|
|
? |
MM0050 |
CAPSCREW - M10 X 1.50 X 35 |
4 |
|
|
|
|
? |
EC3370 |
STRIP, WEATHER |
1 |
|
|
|
|
? |
EC3371 |
STRIP, WEATHER |
1 |
|
|
|
|
? |
CH3409 |
CABLE, BATTERY - R.H. |
1 |
|
|
|
|
? |
VN9907 |
CLAMP |
3 |
|
|
|
|
? |
TG2568 |
CLAMP |
28 |
|
|
|
|
? |
MM0641 |
WELD STUD - M8 X 20 |
10 |
|
|
|
|
? |
MM0470 |
LOCKWASHER - M8 |
22 |
|
|
|
|
? |
MM0460 |
FLAT WASHER - M8 |
22 |
|
|
|
|
? |
MM0177 |
NUT - M8 X 20 |
22 |
|
|
|
|
? |
EC4411 |
CABLE, BATTERY - R.H. |
1 |
|
|
|
|
? |
CH2716 |
CABLE, BATTERY |
1 |
|
|
|
|
? |
EG3572 |
BATTERY BOX ASSEMBLY - R.H. |
1 |
|
|
|
|
? |
CH2723 |
CABLE, BATTERY |
1 |
|
|
|
|
? |
VC1387 |
CAPSCREW - 1/2" - 13NC X 1" |
4 |
|
|
|
|
? |
TR6008 |
FLAT WASHER - 1/2" |
4 |
|
|
|
|
? |
TR5445 |
LOCKWASHER - 1/2" |
4 |
|
|
|
|
? |
CH2924 |
CABLE, BATTERY CHARGING ALTERNATOR |
1 |
|
|
|
|
? |
EC4419 |
CABLE, STARTER |
1 |
|
|
|
|
? |
CH2717 |
CABLE, STARTER |
1 |
|
|
|
|
? |
CH2724 |
CABLE, GROUND |
1 |
|
|
|
|
? |
CH2933 |
CABLE, BATTERY |
1 |
|
|
|
|
? |
VZ1369 |
LOCKNUT, CONDULET |
2 |
|
|
|
|
? |
SD5211 |
BUSHING, PIPE |
2 |
|
|
|
|
? |
MM0461 |
FLAT WASHER - M10 |
4 |
|
|
|
|
? |
MM0471 |
LOCKWASHER - M10 |
4 |
|
|
|
|
? |
MM0178 |
NUT - M10 X 1.50 |
4 |
|
|
|
