| Наименование | Страница | Код страницы |
|---|---|---|
| LIGHT ASSEMBLY (SUPER HALOGEN) - 2 | 276 | 40869 |
| LIGHT ASSEMBLY (SUPER HALOGEN) - 2 | 276 | 40869 |
| LIGHT ASSEMBLY (SUPER HALOGEN) - 2 | 276 | 40869 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | AK3359 | TAIL & STOP LIGHT ASSM (SEE FIG 40869) | 2 | 40869 | |||
| ? | SP8708 | LOCKWASHER - 3/8" | 6 | ||||
| ? | AK3357 | TURN/CLEARANCE LIGHT ASSEMBLY (SEE FIG 40869) | 2 | 40869 | |||
| ? | AK3320 | BACK-UP LIGHT ASSEMBLY (SEE FIG 40869) | 2 | 40869 | |||
| ? | 424243 | CLAMP | 1 | ||||
| ? | MM0642 | WELD STUD - M8 X 25 | 5 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 9 | ||||
| ? | MM0177 | NUT - M8 X 1.25 | 11 | ||||
| ? | 720462 | CLAMP | 2 | ||||
| ? | 736131C2 | HORN, BACK-UP | 2 | ||||
| ? | MM0594 | CAPSCREW - M8 X 1.25 X 25 | 4 | ||||
| ? | SP6153 | LOCKWASHER - 3/8" (EXTERNAL/INTERNAL TOOTH) | 2 | ||||
| ? | VZ3028 | GRIP, CORD | 1 | ||||
| ? | EG0015 | HARNESS - REAR LIGHTS & BACK-UP HORN | 1 | ||||
| ? | VN9907 | CLAMP | 1 | ||||
| ? | TG2562 | CLAMP | 1 |
