| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VS0035 | DOME LIGHT | 2 | ||||
| ? | SR6747 | • LAMP, MINIATURE | 2 | ||||
| ? | TM9090 | • INSULATOR | 2 | ||||
| ? | VZ0598 | TYRAP | 4 | ||||
| ? | EF6943 | HARNESS, INTERNAL | 1 | ||||
| ? | VZ3250 | DIODE | 2 | ||||
| ? | EF8492 | HARNESS, FLUID COMPONENT | 1 | ||||
| ? | PB6783 | SWITCH, PRESSURE | 1 | ||||
| ? | PB6784 | SWITCH, PRESSURE | 1 | ||||
| ? | PB6785 | SWITCH, PRESSURE | 1 | ||||
| ? | PB6992 | SWITCH, PRESSURE | 1 | ||||
| ? | PB7069 | TIMER | 1 | ||||
| ? | SG3408 | NUT - #10 - 24NC | 2 | ||||
| ? | PB4767 | RELAY | 1 | ||||
| ? | DL4172 | SLEEVE, INSULATING | 2 | ||||
| ? | SF9896 | DISCONNECT, KNIFE | 2 | ||||
| ? | VF2231 | MACHINE SCREW - #10 - 24NC X 3/8" | 6 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 6 | ||||
| ? | PB9862 | CAP, PROTECTIVE METAL | 1 | ||||
| ? | WA5641 | MACHINE SCREW - #4 - 40NC X 3/8" | 4 | ||||
| ? | SM2117 | PLATE, NUT | 1 | ||||
| ? | SM0721 | GASKET | 1 | ||||
| ? | SF0542 | MACHINE SCREW - #4 - 40NC X 5/16" | 1 | ||||
| ? | VD7129 | LOCKWASHER - #4 | 1 | ||||
| ? | VN9717 | NUT - #4 - 40NC | 1 | ||||
| ? | MM0581 | CAPSCREW - M6 X 1.00 X 16 | 4 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 4 | ||||
| ? | MM0176 | NUT - M6 X 1.00 | 4 | ||||
| ? | SM2784 | PLATE, MOUNTING | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | WA4328 | PLATE, DANGER (INSIDE L. DOOR) | 1 | ||||
| ? | WA4329 | PLATE, HI-PRESSURE WARNING (INSIDE L. DOOR) | 1 | ||||
| ? | WA3134 | DRIVE SCREW - #6 X #10 | 8 |
