| Наименование | Страница | Код страницы |
|---|---|---|
| LIGHT ASSEMBLY (SUPER HALOGEN) - 2 | 276 | 40869 |
| R.H./L.H. LADDER WIRING | 242 | 55050 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EF8489 | HARNESS - RIGHT UPRIGHT | 1 | ||||
| ? | EC3267 | LADDER ASSEMBLY - R.H. (SEE FIG 55050) | 1 | 55050 | |||
| ? | AK3321 | SERVICE LIGHT ASSEMBLY | 1 | ||||
| ? | AK7552 | • HOUSING | 1 | ||||
| ? | AK7575 | • BULB - 24V/60W | 1 | ||||
| ? | AK3338 | • LENS, GLASS | 1 | ||||
| ? | SP6153 | LOCKWASHER - 3/8" (INTERNAL TOOTH) | 1 | ||||
| ? | TG2960 | CLAMP | 6 | ||||
| ? | MM0713 | FLAT WASHER - M10 | 17 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 17 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 17 | ||||
| ? | WA4649 | CLAMP | 3 | ||||
| ? | 720462 | CLAMP | 6 | ||||
| ? | MM0024 | CAPSCREW - M10 X 1.50 X 16 | 2 | ||||
| ? | VN5153 | WIRE, GROUND | 1 | ||||
| ? | AK3357 | TURN SIGNAL & CLEARANCE LIGHT (SEE FIG 40869) | 1 | 40869 | |||
| ? | TD2186 | GROMMET | 1 | ||||
| ? | EF8487 | HARNESS - RIGHT DECK | 1 |
