| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EG1073 | HANDRAIL, L.H. FRONT | 1 | ||||
| ? | EG0632 | HANDRAIL, L.H. REAR | 1 | ||||
| ? | MM0617 | CAPSCREW - M12 X 1.75 X 25 | 26 | ||||
| ? | MM0462 | FLAT WASHER - M12 | 26 | ||||
| ? | MM0472 | LOCKWASHER - M12 | 26 | ||||
| ? | EG8729 | DECK, LEFT | 1 | ||||
| ? | MM0128 | CAPSCREW - M20 X 2.50 X 110 | 6 | ||||
| ? | EC7594 | FLAT WASHER - M20 | 6 | ||||
| ? | EG9144 | SPACER | 6 | ||||
| ? | MM0697 | NUT - M20 X 2.50 (LOCKING) | 6 | ||||
| ? | ED6111 | PAD, TAPPED | 11 | ||||
| ? | ED6112 | PAD, TAPPED | 1 | ||||
| ? | C1605 | CAPSCREW - 3/8" - 16NC X 1 3/4" | 6 | ||||
| ? | TJ6525 | PAD, TAPPED | 2 | ||||
| ? | EG0639 | CHAIN ASSEMBLY | 2 | ||||
| ? | TB8588 | ROD, FORMED | 4 | ||||
| ? | AK4069 | MIRROR ASSEMBLY | 1 | ||||
| ? | AK4218 | • MIRROR GLASS KIT | 1 | ||||
| ? | AK4219 | • LOCKING STRIP KIT | 1 | ||||
| ? | MM0607 | CAPSCREW - M10 X 1.50 X 35 | 4 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 6 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 6 | ||||
| ? | TZ2083 | MOUNT, MIRROR | 1 | ||||
| ? | TJ6977 | GUSSET | 1 | ||||
| ? | HE5611 | NUT, LOCKING | 2 | ||||
| ? | EG9108 | BRACE, TUBE | 1 | ||||
| ? | EG9107 | BRACE | 1 | ||||
| ? | EG9109 | BRACKET | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | EG0565 | LADDER, SERVICE - LEFT UPRIGHT (LOWER REAR) | 1 | ||||
| ? | TV1748 | CAPSCREW - 5/8" - 11NC X 1 1/2" | 2 | ||||
| ? | WA4863 | FLAT WASHER - 5/8" | 4 | ||||
| ? | VN9952 | LOCKNUT - 5/8" | 2 |
