Номер на схеме	Каталожный номер	Название	Количество
?	VE4146	O-RING (1)	4
?	VE4147	O-RING (1)	4
?	VE4148	O-RING (1)	2
?	VE4149	O-RING (1)	4
?	VE4150	SEAL (1)	4
?	VE4151	SEAL (1)	1
?	VE4152	O-RING (1)	2
?	VE4153	O-RING (1)	2
?	VE4154	O-RING (1)	1
?		HOUSING/SPOOLS (2)	1
?	VE4155	SCREW	2
?	VE4156	WASHER, SPRING	2
?	VE4157	SCREW	16
?	VE4158	WASHER, SPRING	16
?	VE4159	COVER	1
?	VE4160	COVER	1
?	VE4181	SPRING
?	VE4182	SPRING
?	VE4163	VALVE, RELIEF	1
?	VE4164	PLUG	1
?	VE7274	VALVE ASSEMBLY	2
?	VE4166	STOP	1
?	VE4167	STOP	2
?	VE4168	CONTROL, SPRING	2
?		DRIVE SCREW (2)	2
?		NAME PLATE (2)	1
?	VE4169	ORIFICE	1
?	VE4170	SPRING	2
?	VE4171	SPRING	2
?	VE4172	SPRING	1
?	VE4173	ORIFICE	2
?	VE4174	ORIFICE	1
?	VE4175	ORIFICE	1
?	VE4176	VALVE, CHECK	1
?	VE4177	PLUG	1
?	VE4178	WASHER	1
?		PLUG (2)	1
?	VE7275	PLUG	1
?	VE4180	VALVE	1
?	VE4183	NOTE: (1) INCLUDED IN VE4183 SEAL KIT.
?		• (2) HOUSING, AMPLIFIER STAGE, PRIORITY VALVE
?		• • SPOOL AND DIRECTIONAL SPOOL ARE NOT
?		• • SERVICED SEPARATELY.
