| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VZ1988 | BEARING (1) | 1 | ||||
| ? | VZ1987 | SEAL (1) | 1 | ||||
| ? | ED3847 | PISTON | 1 | ||||
| ? | VL7694 | LOCKNUT - 1 3/4" - 5NC (1) | 1 | ||||
| ? | ED4609 | HOUSING, CYLINDER | 1 | ||||
| ? | ED4602 | GLAND | 1 | ||||
| ? | TD8516 | CAPSCREW - 3/4" - 10NC X 3 1/2" - G8 | 2 | ||||
| ? | VM4571 | CAPSCREW - 3/4" - 10NC X 2 1/2" - G8 | 4 | ||||
| ? | ED3850 | ROD | 1 | ||||
| ? | PB8937 | WIPER, ROD (1) | 1 | ||||
| ? | PC0557 | SEAL, ROD (1) | 1 | ||||
| ? | PB9518 | BEARING, ROD (1) | 1 | ||||
| ? | WA1436 | BACKUP, RING (1) | 1 | ||||
| ? | WA0436 | O-RING (1) | 1 | ||||
| ? | C1613 | CAPSCREW - 1/2" - 13NC X 1 1/4" (2) | 16 | ||||
| ? | C1540 | LOCKWASHER - 1/2" (2) | 16 | ||||
| ? | ED3846 | RETAINER (2) | 2 | ||||
| ? | PC0827 | BUSHING, BALL (2) | 2 | ||||
| ? | AK3853 | NOTE: (1) INCLUDED IN AK3853 STEERING CYL REBUILD KIT. | |||||
| ? | (2) NOT INCLUDED IN ASSEMBLY. |
