| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | AK4058 | RIM - 57" X 32" | 1 | ||||
| ? | AK7754 | RING, FORGED - 1" X 6 1/2" | 2 | ||||
| ? | AK8010 | BAND, BEAD SEAT - 57" | 1 | ||||
| ? | PB6512 | O-RING | 1 | ||||
| ? | AK8014 | RING, LOCK - 57" | 1 | ||||
| ? | PB8881 | PLUG | 1 | ||||
| ? | PB8882 | SPUD, DOUBLE | 1 | ||||
| ? | PB8885 | EXTENSION, FLEXIBLE - 10 3/4" | 1 | ||||
| ? | VJ8012 | HOUSING, CORE | 1 | ||||
| ? | WA2670 | CAP, VALVE | 1 | ||||
| ? | WA4649 | CLAMP | 2 | ||||
| ? | S5716 | CAPSCREW - 1/4" - 20NC X 7/8" | 2 | ||||
| ? | VN9773 | FLAT WASHER - 1/4" | 2 | ||||
| ? | C5774 | LOCKWASHER - 1/4" | 2 | ||||
| ? | C5780 | NUT - 1/4" | 1 | ||||
| ? | ED4083 | PLATE, BENT | 1 | ||||
| ? | EH3437 | STUD, HEADED | 50 | ||||
| ? | WA5657 | NUT, FLANGED - 1 1/4" - 12 NF | 50 | ||||
| ? | EG7678 | SPACER, WHEEL | 1 | ||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
