| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | REAR AXLE & SUSPENSION | ||||||
| ? | WB2507 | • DECAL, WARNING HIGH VOLTAGE (FACE OF REAR AXLE DOORS) | 1 | ||||
| ? | WB2518 | • DECAL, HOT AIR | 5 | ||||
| ? | TY1549 | • SEAL, REAR AXLE DOOR | 1 | ||||
| ? | WB2529 | • DECAL, WHEEL MOTOR (CHECK OIL LEVEL) | 4 | ||||
| ? | FRAME & FUEL TANK - R.H. | ||||||
| ? | WB2522 | • DECAL WARNING - RAISED BODY (FACE FUEL TANK) | 2 | ||||
| ? | WB2510 | • DECAL WARNING - CLEARANCE REDUCED TURNING (FRAME BEHIND & FORWARD FRONT WHEEL) | 4 | ||||
| ? | WB2523 | • DECAL, DANGER - HIGH PRESSURE | 1 | ||||
| ? | FRAME & HYDRAULIC TANK - L.H. | ||||||
| ? | WB2523 | • DECAL, DANGER - HIGH PRESSURE ACCUMULATOR (FRAME BY ACCUMULATOR) | 1 | ||||
| ? | WB2525 | • DECAL, NON-PRESSURIZED | 1 | ||||
| ? | WB2524 | • DECAL, WARNING - HIGH PRESSURE (FACE OF HYD TANK) | 1 | ||||
| ? | WA6631 | • DECAL, CAUTION - ADD OIL HYD TANK (SIDE HYD TANK) | 1 | ||||
| ? | WA9755 | • DECAL, EMERGENCY DUMP PROCEDURES (BEHIND LEFT HOIST CYL ON FRAME) | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | WB2528 | EMERGENCY TOWING | 1 | ||||
| ? | NOTE: (1) USE WA3134 DRIVE SCREW AS REQUIRED. |
