| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE3543 | COVER, SPOOL | 1 | ||||
| ? | VE3535 | BALL (2)/(3) | 1 | ||||
| ? | VE3536 | POPPET (2) | 1 | ||||
| ? | VE3527 | O-RING (2)/(3) | 1 | ||||
| ? | VE3548 | SEAT, SPRING | 4 | ||||
| ? | VE3541 | SPRING | 2 | ||||
| ? | VE3545 | PLUG | 3 | ||||
| ? | VE3539 | POPPET (2) | 1 | ||||
| ? | VE3546 | SPOOL END | 4 | ||||
| ? | VE3547 | SPOOL (1) | 2 | ||||
| ? | VE3542 | SPRING | 2 | ||||
| ? | VE5472 | POPPET (2) | 1 | ||||
| ? | VE7619 | HOUSING, SPOOL (1) | 1 | ||||
| ? | VE3533 | O-RING (2)/(3) | 4 | ||||
| ? | VE3603 | POPPET (2) | 1 | ||||
| ? | VJ2946 | O-RING (2)/(3) | 2 | ||||
| ? | VJ1983 | PLUG | 1 | ||||
| ? | VE3549 | O-RING (2)/(3) | 1 | ||||
| ? | VE3544 | COVER, SPOOL | 1 | ||||
| ? | (NOT USED THIS APPLICATION) | ||||||
| ? | (NOT USED THIS APPLICATION) | ||||||
| ? | VE3538 | POPPET (2) | 1 | ||||
| ? | VE3540 | POPPET (2) | 1 | ||||
| ? | NOTE: (1) NOT SERVICED SEPARATELY. | ||||||
| ? | BF3047 | • (2) INCLUDED IN BF3047 MAJOR SERVICE KIT. | |||||
| ? | BF3048 | • (3) INCLUDED IN BF3048 MINOR SERVICE KIT. |
